主要技术参数 Main Technical Parameter
|
参数/型号 Parameter/model |
TMF-50KVA |
TMF-90KVA |
TMF-150KVA |
TMF-170KVA |
TMF-250KVA |
TMF-300KVA |
||
|
额定电源 Rated/Voltage |
3相，交流电（AC），380------415-----480V，50/60HZ |
|||||||
|
额定容量 Rated/Capacity |
50KVA |
90KVA |
150KVA |
170KVA |
250KVA |
300KVA |
||
|
额定占截率 Rated Duty Cycle |
50% |
50% |
50% |
50% |
50% |
50% |
||
|
最大焊接电流 Max Welding Current |
18500A |
23500A |
32000A |
40500A |
56500A |
80000A |
||
|
电极行程 Electrode Stroket |
75MM |
100MM |
||||||
|
电极臂间距 Welding Arm Spacing |
260MM |
320MM |
||||||
|
气源压力 Air Source Pressure |
0.6MPa |
|||||||
|
冷却水流量 Cooling Water Flow |
16L/Minute |
25L/Minute |
35L/Minute |
45L/Minute |
||||
