用途：该机主要用于包装中草药，花茶、枸杞、板蓝根、瓜子,月饼等颗粒的小型包装袋。
This machine is mainly used for packing small packing bags of Chinese herbal medicine, scented tea, Medlar, Banlangen, melon seeds, moon cake and other granules.
技术参数/Technical parameter:
|
型号/Model |
SN-2518K |
SN-2815K |
|
SN-2828K |
SN-4530K |
|
|
包装速度/Packing speed |
30-50 bags/min |
30-80 bags/min |
|
30-50 bags/min |
10-40 bags/min |
|
|
包装范围/Packing range |
1-200ml |
5-200ml |
|
10-350ml |
50-1500ml |
|
|
膜宽/Film width |
≤250mm |
≤ 280mm |
|
≤ 280mm |
|
背封≤ 450mm 三/四边封≤ 380mm |
|
制袋尺寸/Making bag size |
L: 50-180mm, W: 15-115mm |
L: 50-150mm, W: 15-130mm |
|
L: 50-280mm, W: 15-130mm |
|
L: 50-300mm, W: 50-210mm |
|
包装精度/Packing accuracy |
≤ ±1%（根据物料而定/depends on product） |
|||||
|
耗气量/Air consumption |
纯电动，无需空压机 |
|
需要空压机 0.8Mpa,0.5m3/min |
|||
|
功率/Power |
1.6KW |
1.6 KW |
|
1.6 KW |
1.9 KW |
|
|
电源/Power supply |
1ph,AC220V, 50/60Hz |
|||||
|
封口类型/Seal type |
（3边封/4边封//背封）3/4 sides seal, pillow seal |
|||||
|
净重/Net weight |
230KG |
250kg |
|
300kg |
350kg |
|
|
机器尺寸/Machine dimension |
L680 × W730 × H1700mm |
L800 × W680 × H1800mm |
|
L800 × W680 × H1900mm |
|
L1100 × W800 × H1900mm |
|
材质 |
主体外壳304不锈钢 接触物料304不锈钢 |
主体外壳201不锈钢 接触物料304不锈钢 |
||||
|
控制系统 |
PLC控制 |
电脑控制 |
|
电脑控制 |
PLC控制 |
|
|
操作界面 |
彩色触摸屏 |
|||||
