3M5930
3M
VHB? Tape
5915 ? 5930
Product DeSCRJPTion 3M? VHB? Acrylic Foam Tapes 5915 and 5930 are pressure sensitive adhesive
tapes for bonding a wide range of materials, including many paints and lower surface
energy plastics in addition to metals and other plastics. The foam is conformable to
increase contact with the surfaces. This tape is similar to other products in the 3M?
VHB? Tape 5952 family except thickness.
Technical Data December, 2007
Construction Product 3M? VHB? Tape
5915 5930
Adhesive: Modified Acrylic
Adhesive Carrier: Very Conformable Acrylic Foam (closed cell)
Thickness: 0.016 in. (0.4 mm) 0.032 in. (0.8 mm)
Density: 43 lb./ft.3 (690 kg/m3) 37 lb./ft.3 (590 kg/m3)
Liner: Red polyethylene film
Tape Color: Black
Product 3M? VHB? Tape
5915 5930
Peel Adhesion: 13 lb./in. width 18 lb./in. width
(stainless steel) (230 N/100 mm) (315 N/100 mm)
Normal Tensile: 90 lb./in.2 (620 kPa) 90 lb./in.2 (620 kPa)
(aluminum T-block)
Dynamic Shear: 90 lb./in.2 (620 kPa) 85 lb./in.2 (585 kPa)
(stainless steel)
Static Shear:
(stainless steel) 72°F (22°C) 1000 g/0.5 sq. in. (holds 10,000 min.)
158°F (70°C) 500 g/0.5 sq. in. (holds 10,000 min.)
200°F (93°C) 500 g/0.5 sq. in. (holds 10,000 min.)
250°F (121°C) 250 g/0.5 sq. in. (holds 10,000 min.)
Solvent Resistance: High
Temperature Resistance:
Short Term: (minutes, hours) 300°F (149°C)
Long Term: (days, weeks) 250°F (121°C)
Typical Physical
Properties and
Performance
Characteristics
Note: The following technical information and data should be considered representative
or typical only and should not be used for specification purposes.
3M? VHB? Tape
5915 ? 5930
Application Guidelines For maximum bond strength the surfaces should be thoroughly cleaned with a 50:50
mixture of isopropyl alcohol and water. Consult manufacturers directions for use and
precautions when using cleaning solvents. Ideal tape application is accomplished
when temperature is between 70° and 100°F (between 21° and 38°C) and the bond is
allowed to dwell 72 hours. Initial tape application to surfaces at temperatures below
50°F (10°C) is not recommended.
Storage The optimum storage conditions are 72°F (22°C) and 50% relative humidity.
Shelf Life 24 months from date of manufacture when stored at 40° to 100°F (4° to 38°C) and
0-95% relative humidity.
All statements, technical information and recommendations contained in this document are based upon
tests or experience that 3M believes are reliable. However, many factors beyond 3M’s control can affect
the use and performance of a 3M product in a particular application, including the conditions under
which the product is used and the time and environmental conditions in which the product is expected
to perform. Since these factors are uniquely within the user’s knowledge and control, it is essential that
the user evaluate the 3M product to determine whether it is fit for a particular purpose and suitable for
the user’s method of application.
Product Use
If the 3M? VHB? Tape is proved to be defective within the warranty period stated above. THE
EXCLUSIVE REMEDY, AT 3M’S OPTION, SHALL BE TO REFUND THE PURCHASE PRICE OF OR
TO REPAIR OR REPLACE THE DEFECTIVE 3M? VHB? TAPE. 3M shall not otherwise be liable for
loss or damages, whether direct, indirect, special, incidental, or consequential, regardless of the legal
theory asserted, including negligence, warranty, or strict liability.
Limitation of Remedies
and Liability
This Industrial Adhesives and Tapes Division product was manufactured under a 3M quality system registered to ISO 9001:2000 standards.
ISO 9001:2000
3M warrants for 24 months from the date of manufacture that 3M? VHB? Tape will be free of defects
in material and manufacture. 3M MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. This limited warranty does not cover damage resulting
from the use or inability to use 3M? VHB? Tape due to misuse, workmanship in application, or
application or storage not in accordance with 3M recommended procedures. AN APPLICATION
WARRANTY EXPRESSLY APPROVED AND ISSUED BY 3M IS AN EXCEPTION. THE CUSTOMER
MUST APPLY FOR A SPECIFIC APPLICATION WARRANTY AND MEET ALL WARRANTY AND
PROCESS REQUIREMENTS TO OBTAIN AN APPLICATION WARRANTY. CONTACT 3M FOR MORE
INFORMATION ON APPLICATION WARRANTY TERMS AND CONDITIONS.
Limited Warranty
3M and VHB are trademarks of 3M.
Printed in U.S.A.
©3M 2007 70-0709-4027-8 (12/07)
Recycled Paper
40% pre-consumer
10% post-consumer
3
Industrial Adhesives and Tapes Division
3M Center, Building 21-1W-10, 900 Bush Avenue
St. Paul, MN 55144-1000
800-362-3550 ? 877-369-2923 (fax)
www.3M.com/industrial
Standard Length: 72 yds. (65.8 m)
Minimum Width: 1/4 in. (6.4 mm)
Slitting Tolerance: ± 1/32 in. (± 0.8 mm)
Core Size (ID): 3.0 in. (76.2 mm)
Available Sizes
