索尼CCD工业相机XC-ST30CE

XC-ST30

1/3寸隔行扫描,38万像素,560线,EIA格式,黑白小型,高速工业相机

采用1/3寸HAD技术高灵敏度CCD
所用控制部分都在机身外部,便于控制
高信噪比:58dB
简单灵活的触发功能
新型的EIAJ 12PIN引线分配，可以接收触发脉冲
小巧，紧凑机身- 29 (W) x 29 (H) x 32 (D)/50g
优异的防震动,防抖动性能(10G-70G)
小巧的电源(DC-700/DC-700CE)

指标                                    详细
成像器件                              1/3寸IT逐行扫描CCD
成像器件色值                       单色黑白
有效分辨率                           768X494
相机界面                             模拟
镜头安装方式                        C-Mount
Flange Back                       17.526 mm
垂直频率                              59.94Hz
水平频率                              15.625kHz
外同步信号                            HD/VD
外同步频率                           +/- 1%
JITTER（颤抖值）                 低于+/- 50 nsec
同步系统                             内同步/外同步
扫描系统                              2:1隔行
增益                                    AGC自动(0-18dB)
                                          MANUAL手动（0-18dB)可选 FIXED固定(0dB)可选
Gamma                              ON开/OFF关
标准快门；                           1/120 to 1/10000 s
外触发快门/速度                 1/4 to 1/10000s
快门速度                              1/100 to 1/10000
水平分辨率                           570TV线
最低照度                              0.3 lux F1.4
输出连接口                           12PIN
信噪比                                 56dB
灵敏度                                 400 lux F11
信号系统                              EIA标准
视频输出                              1.0 Vp-p Sync negative75?
                                          Unbalanced
综合指标                             详细情况
尺寸(W x H x D)                  (44X 29 X57.5mm)
重量                                    110 g (2 oz)
电源要求                              DC 12 V (+9 to 16V)
功率消耗                              1.9 W
工作温度                              -5 to 40°C (23 to 113 °F)
存放温度                              -30 to 60 °C (-22 to 140 °F)
工作湿度                              20 to 80 % (无凝固情况下)
存放湿度                              20 to 95 % (无凝固情况下)
抖动抵抗限度                        10G (20 Hz to 200 Hz)
震动抵抗限度                        70 G
符合标准                              UL 1492 FCC Class A Digital Device
                                          CE (EN61326/97+A1/98)
                                          AS4251.1+A4252.1
尺寸：                                 (W x H x D)(29 x 29 x 30 mm)
标准附件：
镜头盖1个
操作手册1本
可选附件:
型号                                   名称
VCL12YM                            1/2",C-MOUNT镜头,12mm
VCL25YM                            2/3" C Mount镜头, 25mm
VCL50YM                            2/3" C Mount镜头, 50mm
CCXC12P10N                     10米摄像机线(XC系列专用)
CCXC12P05N                      5米摄像机线(XC系列专用)
DC-700 /DC-700CE            摄像机电源(XC-EIA /XC-CCIR系列专用)
CCXC12P02N                      2米摄像机线(XC系列专用)
VCTST701三角架                 XC系列专用
