Absolute Maximum Ratings
|
Parameter |
Symbol |
Min |
Max |
Unit |
|
Supply Voltage 1 |
Vcc3 |
-0.5 |
4.0 |
V |
|
Supply Voltage 2 |
Vcc5 |
-0.5 |
6.0 |
V |
|
Storage Temperature |
Tst |
-40 |
85 |
oC |
|
Optical Input Received Power |
PIN |
- |
+4 |
dBm |
Operating Conditions
|
Parameter |
Symbol |
Min |
Typical |
Max |
Unit |
|
Supply Voltage 1 |
Vcc3 |
3.13 |
3.3 |
3.47 |
V |
|
Supply current 1 |
Icc3 |
|
|
750 |
mA |
|
Supply Voltage 2 |
Vcc5 |
4.75 |
5 |
5.25 |
V |
|
Supply current 2 |
Icc5 |
|
|
500 |
mA |
|
Operating Case temperature |
Tca |
-5 |
- |
70 |
oC |
|
Module Power Dissipation |
Pm |
- |
|
3.5 |
W |
Transmitter Specifications – Optical
|
Parameter |
Symbol |
Min |
Typical |
Max |
Unit |
|
Data Rate Multirate |
Mra |
9.95 |
- |
11.3 |
Gbps |
|
Center Wavelength (SOL)△ |
lc |
lc -25 |
lc |
lc +25 |
pm |
|
Center Wavelength (EOL)▲ |
lc |
lc -100 |
lc |
lc+100 |
pm |
|
Optical Transmit Power |
Po |
-1 |
- |
+2 |
dBm |
|
Optical Transmit Power (disabled) |
PTX_DISABLE |
- |
- |
-40 |
dBm |
|
Extinction Ratio |
ER |
8.2 |
|
- |
dB |
|
Channel Spacing |
??f |
- |
100 |
- |
GHz |
|
Jitter Generation |
TJP-P |
- |
- |
0.1 |
UI |
|
Spectral Width (-20dB) |
Dl20 |
- |
0.1 |
0.3 |
nm |
|
Side Mode Suppression Ratio |
SMSR |
30 |
- |
- |
dB |
|
Dispersion penalty(800ps/nm) |
DP |
|
|
2 |
dB |
|
Eye Mask |
Compliant with ITU-T G.691 STM-64 eye mask |
||||
△Laser- Start of Life
▲Laser End of life
PIN Receiver Specifications – Optical
|
Parameter |
Symbol |
Min |
Typical |
Max |
Unit |
|
Data Rate Multirate |
Mra |
9.95 |
- |
11.3 |
Gbps |
|
Receiver Sensitivity |
Rsens |
- |
- |
-15 |
dBm |
|
Receiver Sensitivity (OSNR = 20dB) |
Rsens-2 |
- |
- |
-24 |
dBm |
|
Maximum Input Power |
RX-overload |
- |
- |
-1 |
dBm |
|
Input Operating Wavelength |
λ |
1528 |
- |
1564 |
nm |
|
Reflectance |
Rrx |
- |
- |
-27 |
dB |
|
Loss of Signal Asserted |
|
-28 |
- |
- |
dBm |
|
LOS De-Asserted |
|
- |
- |
-22 |
dBm |
|
LOS Hysteresis |
|
0.5 |
- |
- |
dB |
