2.1 台历 挂历 笔记本全自动YO单/双线圈装订机上料装置的调整 Adjust the feed belt
该工位可根据产品的宽窄来调节输送料道的宽度，参考（图九）松开护罩1的固定螺丝123，然后根据产品的需要调整料道的宽窄。The POSTTTION of the station can be adjusted according to the width of the product to adjust the width of the conveyor material, refer to (Picture 9) to release the cover screw 1 123, and then adjust the width of the material according to the needs of the material.
收料装置的调整(参考图三) Adjust the receive belt (Picture 3)
该工位主要是配合主机完成收料工作，可根据主机的装订速度自动调整线体的每次位移. The station is mainly with the host to complete the receipt work, according to the host's binding speed automatically adjust the line of each displacement.
3. 台历 挂历 笔记本全自动YO单/双线圈装订机推刀调试 Test push knife
根据产品大小的需要，可通过调节推刀组的固定螺丝的安装位置来调节T的宽度（见图十）Depending on the size of the product, the width of the T can be adjusted by adjusting the mounting POSTTTION of the setscrews' fixing screws (Picture 10)
4.台历 挂历 笔记本全自动YO单/双线圈装订机孔位自动校正系统的调整 Adjust the corrective system
此工位主要是通过整形针来实现孔位校正的，根据产品的需要可调整整形针间的间距和角度。。This POSTTTION is mainly through the pins to achieve hole correction, according to the needs of the product can adjust the space between the needle and angle.
5.台历 挂历 笔记本全自动YO单/双线圈装订机自动绕线穿线系统的调整 Adjust the inserting system
机器出厂前已装有调试好的一套模具。当机器需要更换模具时，可按照以下步骤进行。The machine is shipped with a good set of molds. When the machine needs to replace the mold, follow the steps below.
5.1 台历 挂历 笔记本全自动YO单/双线圈装订机穿线 Inserting the wire
将线穿入进线组件，经过过线轮24.1，润滑盒25，过线轮24.2,计数轮26（经过计数轮时将线绕计数轮一圈），过线轮24.3,再经过铁线整直板(如图一)，之后在芯棒上.
