额定载荷Rated load |
0～0.1…20t |
精度等级Accuracy grade |
C3 |
|
额定输出Rated outputt |
2.0±0.2%mV/V |
蠕变Creep deformation |
≤±0.03%F.S |
|
滞后误差Lag error |
±0.03%F.S |
线性误差Linear error |
±0.03%F.S |
|
零点输出Zero outputt |
≤±1%R.C |
重复性误差Repeatability error |
≤±0.01%R.C |
|
输入阻抗Input impedance |
385±35Ω |
输出阻抗outputt impedance |
350±3Ω |
|
绝缘电阻Insulation resistance |
≥2000MΩ |
破坏载荷Charge of surety |
150% |
|
输出温度影响outputt temperature effect |
±0.03%F.S/10℃ |
工作温度Temperature |
（-20～70）℃ |
|
零点温度影响Zero temperature effect |
±0.02%F.S/10℃ |
材质Texture |
合金钢或不锈钢 |
|
力值变送器Force value transmitter |
4～20mA、0~10V |
额定电压Rated voltage |
5～15V DC |
