规格说明(specifications):
1.0电气特性(electrical):
1.1额定电流(current rating):
0.5a/contact terminal
1.2额定电压(voltage rating):
30v dc
1.3接触阻抗(contact resistance):
30 milliohms max
1.4耐电压(dielectnic withstanding voitage):
500 v ac at sea levol
1.5绝缘阻抗(insulation resistance):
1000mega ohms min
2.0物理性能(mechanical):
2.1插拔力(cnnector mate and unmate force):
mating force:3.57kgf(max)
unmating force:1.02kgf(min)
2.2端子保持力(terminal retenion):
1.2kgf(min)
3.0原材料(matorial):
3.1塑胶(housing):
hing temperature tnermaplastics
ul 94v-0 lcp white/black
3.2端子(contact):
copper alloy c5210
3.3挂钩(hook):
sus301
3.4外壳(shell):
sus304
4.0电镀(finish):
4.1端子(contact):
piated gold in mating area
sn≥100u′ni≥40u′au=1u′/3u′/5u′/...
5.0dimension marked﹡ msut be controlled in qip.
