Model 型号 |
US-540 |
US-560 |
|
Wire Diameter 线径 |
?1.0～?4.0MM |
?2.0～?6.0MM |
|
Axis 轴数 |
5 |
5 |
|
Wire Feed Wheel Sets 送线轮组数 |
3Sets |
3Sets |
|
Max.Outside Diameter 最大弹簧外径 |
?80mm |
?90mm |
|
Max. Feeding Speed 最大进给速度 |
100m/min |
90m/min |
|
Wire Feeding Axis 送线轴功率 |
5.5KW |
15KW |
|
Cam Axis 凸轮轴功率 |
1.8KW |
2.7KW |
|
Upper Cutter Axis 上切刀轴功率 |
1.8KW |
5.5KW |
|
Lower Cutter Axis 下切刀轴功率 |
1.8KW |
5.5KW |
|
Spacing Axis 间距轴功率 |
1.8KW |
1.5KW |
|
Dimension (LxWxH) 尺寸（长×宽×高） |
1800*1100*1800(mm) |
2100*1500*2100(mm) |
|
Weight (kg) 重量（千克） |
1300kg |
2600kg |
Machine features:
机器特性
1. The machine uses a planetary reducer, which requires no oil filling, reducing the risk of oil immersion in the servo motor. An elastic diaphragm coupling is used as the cutting coupling to reduce damage to the encoder caused by cutting vibration.
行星减速器无需加油，降低伺服电机油浸风险，使用弹性膜片联轴器减少切割振动对编码器的损坏。?
2. The machine uses high-quality materials for special processing of the slide track and skateboard to ensure that the hardness and wear resistance are at their peak.
滑轨滑板采用优质材料特殊处理，确保硬度和耐磨性。
3. The equipment is equipped with a precise detection and tracking system to realize automatic shutdown of unqualified products, thereby improving product quality while ensuring qualification.
配备精确检测跟踪系统，实现不合格产品自动停机，提升质量。
4. The machine adopts a wireless, automatic shut-down design for wire breakage and wire tangling and an uncoiler acceleration function to make production easier and more efficient.
无线自动停机设计，用于断线和缠线，以及解卷加速功能。
5. The machine can be used to produce torsion springs, straight springs, tension springs, rectangular springs, wire forming, spiral springs and various fancy springs and difficult special-shaped springs.
该机可用于生产扭簧、直簧、拉簧、矩形弹簧、钢丝成型、螺旋弹簧以及各种花式弹簧和高难度异形弹簧。
