DW-1.2KW系列无火焰便携手持式感应加热器
Main Application and Characteristics
主要用途及特点
Mainly used for more fast and precisely heating the rusted bolts and seized nuts or micro-encapsulated connections,car repairing.
Thanks to the accurately induction heating,there is no need to use a burning or welding torch which would lead to other components heating up as well.
The additional generator and heator with cooling system guarantees permanent use without unnecessary breaks,can heat much longer time.
Separating Design: the main part is separated from the transformer part,better for heat radiation,to avoid the overheating of the equipment within a short time, and ensure the the machine can work long time.Compared with the similar equipment,it has much stronger performance and much longer heating time.
分体化设计：主机部分与变压器部分分开，更有利于散热，防止变压器部分短时间内过热，确保了设备的长时间运行，与同类设备相比，性能更强，加热时间更久。
The device have already gotten European CE Certificate and fulfills the European Quality Standards!
Including the heating coils which can be shaped flexible and have a long service life as following:
包括多个不同形状的感应加热线圈，形状灵活，可长时间使用：
1.Lateral Heating Coil with diameter 25mm;
2.Longitudinal Heating Coil with diameter 20mm;
3.Flat Heating Coil;Coil wrap around the part at least 3turns.
4.Glow Plug Heating Coil with diameter 14mm;Ideal for precisely heating glow plugs.
5.Injector Heating Coil with diameter 28mm;Ideal for precisely heating injectors.
6.Flexible Heating Coil with length 1100mm.
Technical Data
技术参数
|
Model No. 型号： |
DW-1.2KW |
|
|
Product Quality 质量等级 |
Premium |
|
|
Max Output Power 最大输出功率 |
1.2KW |
|
|
Input Voltage and Power Supply 输入电压 |
220V/110V AC 50Hz/60Hz |
|
|
Net Weight净重 |
Main Induction Generator 感应加热主机部分 |
3.1KG |
|
Dimension尺寸 |
35*25*15CM |
|
|
Net Weight净重 |
Handle Induction Head 感应加热分机部分 |
2.1KG |
|
Dimension尺寸 |
42*10*10CM |
|
