| 加工定制:是 | 操作压力:1.0（Mpa） |
| 水电阻率:15 | 出水量:1000升 |
| 外形尺寸:7000*4000（cm） | 电压:380（V） |
| 水质:超纯水 | 功率:10000（w） |
| 电导率:0.07 | 脱盐率:99.85（%） |
| 单机出力:1000升（/h） | 加工定制: |
| 操作压力: | 水电阻率: |
| 出水量: | 外形尺寸: |
| 电压: | 水质: |
| 功率: | 电导率: |
| 脱盐率: | 单机出力: |
主要工艺流程和出水指标：
Main technical process and standard of output water
※预处理+反渗透+离子交换器（电阻率≥15MΩ.CM）
Pre-treatment+ stage reverse osmosis system+ion exchange (electric conductivity≥15MΩ.CM）
※预处理+二级反渗透+EDI（电阻率≥15MΩ.CM）
Pre-treatment+ stage reverse osmosis system+EDI (electric conductivity≥15MΩ.CM）
※预处理+二级反渗透+脱气膜+EDI +抛光混床（电阻率≥18.25MΩ.CM）
Pre-treatment+ double stage reverse osmosis system+air film+EDI +polishing mixed bed (electric conductivity≥18.25MΩ.CM）
详细工艺需根据原水设计情况进行设计
Details of the design process should be carried out according to the feed water quality.
纯水设备的主要特点
Main technics of pure water treatment equipment
|
▼结合电子工业用水连续生产的特性，采用了全膜法处理工艺（UF+RO+EDI）完成高纯水的制备工作； The electronics industry with the characteristics of continuous production of water, using the entire membrane treatment process (UF + RO + EDI) to complete the preparation of highly pure water work; ▼对于电子行业用水的特性，增强了对水中二氧化硅、重金属和有机碳的脱除； For the water features of electronics industry , enhanced to removal silica, heavy metals and organic carbon in water. ▼采用了氮封水箱解决了电子工业用水要求较高，水的储存容易污染问题； Using nitrogen sealed water tanks to solve the problems of electronics industry require a higher water use, water storage easy to pollution ; ▼采用进口反渗透膜，脱盐率高，使用寿命长，运行成本低廉，产水水质高而稳定；
Adopted import reverse osmosis membranes, desalination rate is high, long service life, the operation cost is low, the output water quality is high and stable.
On-line water quality monitoring and control, real-time monitoring of water quality to ensure safety of water quality.
Automatic control procedure, also equipment with touch screen operation, easy to use, the operation is simple, safe. Correspond with the local water personalized design, considerate stackable design, small floor area, which can meet considerate needs. ▼运行费用及维修成本低，全自动运行，实现无人化管理操作。 Operating costs and maintenance cost low, automatic operation, can realize unmanned management operations. |
