数据|型号 |
YLW-1900MA |
YLW-2300MA |
YLW-2900MA |
YLW-3500MA |
YLW-4100MA |
YLW-4700MA |
YLW-5900MA |
|
供热量×104kcal/h Delivered heat |
160 |
200 |
250 |
300 |
350 |
400 |
500 |
|
热效率% Heating efficiency% |
75 |
75 |
75 |
75 |
75 |
75 |
75 |
|
设计压力MPa Design pressure |
1.1 |
1.1 |
1.1 |
1.1 |
1.1 |
1.1 |
1.1 |
|
最高工作温度℃ Max.working temperature |
320 |
320 |
320 |
320 |
320 |
320 |
320 |
|
介质循环量m3/h Medium circulation |
160 |
160 |
200 |
200 |
260 |
260 |
300 |
|
主管口径DN Diameter of main pipe DN |
150 |
150 |
200 |
200 |
200 |
200 |
250 |
|
装机容量KW Installation capacity |
75 |
90 |
100 |
100 |
120 |
140 |
175 |
|
适用燃料 Applicable fuel |
Ⅱ、Ⅲ类烟煤 soft coal,class ⅡandⅢ |
|
数据|型号 |
YLW-7000MA |
YLW-8200MA |
YLW-9400MA |
YLW-12000MA |
YLW-14000MA |
YLW-16500MA |
YLW-17500MA |
|
供热量×104kcal/h Delivered heat |
600 |
700 |
800 |
1000 |
1200 |
1400 |
1500 |
|
热效率% Heating efficiency% |
75 |
75 |
75 |
75 |
75 |
75 |
75 |
|
设计压力MPa Design pressure |
1.1 |
1.1 |
1.1 |
1.1 |
1.1 |
1.1 |
1.1 |
|
最高工作温度℃ Max.working temperature |
320 |
320 |
320 |
320 |
320 |
320 |
320 |
|
介质循环量m3/h Medium circulation |
340 |
400 |
520 |
600 |
680 |
800 |
1000 |
|
主管口径DN Diameter of main pipe DN |
250 |
250 |
300 |
300 |
350 |
350 |
400 |
|
装机容量KW Installation capacity |
215 |
215 |
270 |
315 |
380 |
460 |
540 |
|
适用燃料 Applicable fuel |
Ⅱ、Ⅲ类 |
