型式/TYPE |
双面单层 Two sides one layer |
|
|
卷取管Shape of winding |
锥型管 A Cone |
|
|
锭数Spindles No. |
4 |
Spindle (锭) |
|
锭速 spindle speed |
8100 (max ) |
rpm |
|
线速度 yarn winding speed |
900 |
m/min |
|
卷绕管尺寸(A )Cone length |
4.5 (max ) |
Inch |
|
成型长度Traverse length |
2 - 4 |
Inch |
|
卷曲直径Take up Bobbin dia |
? 140 |
mm |
|
气压Air pressure |
2 |
KGS |
|
电机Installed power |
1 .2 （ 0.2x4锭 +0.4变压器 ） |
KW |
|
油加热 oil heater |
2 |
KW |
|
尺寸Dimension |
1810x1130x1970 |
mm |
|
机器重量Weight |
580 |
KGS |
|
驱动Drive |
单锭单控系统Individual motor system |
|
|
电压Voltage |
380V 50HZ 3 phase |
|
