类型 |
双面单层 |
Type |
Two sides and single layer |
||
|
锭数 |
128锭（16锭/节X8） |
The Number of Spindles
|
128 spindles (16 sp/sec x 8 sec ) |
||
|
长度（mm/节） |
1830mm |
Length ( mm/section) |
1830mm |
||
|
整机尺寸（L*W*H mm） |
16500*700*1540mm |
Overall dimension (L*W*H mm) |
16500*700*1540mm |
||
|
锭速 |
5000-15000 r/m |
The speed of Spindles(r/m) |
5000-15000 r/m |
||
|
捻度范围 |
50-800TPM |
Range of Covering Twist Number(T/M) |
50-800TPM |
||
|
捻向 |
S or Z |
Twist Direction |
S or Z |
||
|
卷取管 |
长度180mm以内 |
Take-up Bobbin Size (mm) |
Length≤180mm |
||
|
收卷型式 |
电子成型 |
Take up forming mode |
Electronic forming |
||
|
电机 |
主电机 |
5.5 KW *1 |
Intalled power (kw )
|
Main motor |
5.5 KW *1 |
|
减速电机 |
1.5KW *1 |
Gear motor |
1.5KW *1 |
||
|
伺服电机 |
1.5KW * 1 |
Servo motor |
1.5KW * 1 |
||
|
电压 |
380V, 3Phase, 50 HZ |
Voltage |
380V, 3Phase, 50 HZ |
||
|
磨毛处理方式 |
自吸式 |
Sueding method |
Self-suction |
||
