邦普睿科技（厦门）有限公司代理销售CAT PUMPS 泵浦
邦普睿科技（厦门）有限公司是美国Cat Pumps International Group 与英国Hughes Pumps 正式授权中国指定代理。专业提供自制的专业生产工业用高压清洗机、高压水射流设备、高压柱塞泵的选型、专业的技术咨询和维#修#服务，欢迎洽询及选购 35 Frame Plunger Pump ?3520,3520C ?3521,3521C ?3527 Brass Standard and? Flushed Stainless Steel Standard and? Flushed Nickel Aluminum Bronze Standard SPECIFICATIONS ?U.S. Measure Metric Measure Flow .........................................................................23 gpm (87 lpm) Pressure Range .....................................100 to 2000 psi (7 to 140 bar) Inlet Pressure Range ........................Flooded to 70 psi (Flooded to 4.9 bar) RPM.........................................................................800 rpm (800 rpm) Bore ............................................................................1.260” (32 mm) Stroke .........................................................................1.890” (48 mm) Crankcase Capacity .............................................4.2 Qts. (4 l) Maximum Liquid Temperature .........................160°F (71°C) Above 130°F call CAT PUMPS for inlet conditions and elastomer recommendations. Inlet Ports (2) ................................................1-12” NPTF (1-12 NPTF) Flushing Ports (2) (3520C, 3521C) ............14” NPTF (14” NPTF) Discharge Ports (2) .............................................1” NPTF (1” NPTF) Pulley Mounting ...........................................Either Side (Either Side) Shaft Diameter ...................................................... 1.378” (35 mm) Weight ....................................................................139 lbs. (63 kg) Dimensions (3520, 3520C,) ..........23.86 x 18.11 x 9.72” (606 x 460 x 247 mm) Dimensions (3521 3521C, 3527) 24.33 x 18.11 x 9.72” (618 x 460 x 247 mm)
