E5P4K-TA/D/I/20/V-D12K5迪普马电液换向阀
防爆型电液方向控制阀 EEx-dIIC 序列号 20
E5P4K CETOP 08
概述：该阀为电磁方向控制阀，其电磁铁完全符合 CENELEC EN 50.014、EN 50.018, CEI 31-1 及 CEI 31-8, 分级标准 EEx-dIIC-T5。电磁铁采用特殊结构，该阀可在有易燃易爆气体的危险工作环境下安全工作。根据需要，可提供 CESI EX-90.C.077  认证。
最大工作压力：
- 油口 P A B （标准型） 320 bar
- 油口 P A B （H型） 420 bar
最大工作流量：
- 从油口P 到 A-B-T 600 l/min
环境温度范围：-20 - +50 °C
油液温度范围：-20 - +80 °C
油液粘度范围：10 - 400 cSt
推荐油液粘度：25 cSt
油液清洁度：NAS 1638 10级
质量：
- 单电磁铁阀 16.0 kg
- 双电磁铁阀 17.2 kg
供应商信息：上海心雨机电设备有限公司
Attn：闫菲18717727482
Email：395717253@qq.com
Tel：021-60510250
Fax：021-55032831
QQ：395717253
江间波浪兼天涌，塞上风云接地阴。 —— 杜甫《秋兴八首·其一》
E5P4K-TA/D/I/20/V-D12K5迪普马电液换向阀
意大利迪普马 电液阀 换向阀 方向控制阀 方向阀 Duplomatic 电磁阀 防爆阀 液压阀
Duplomatic Oleodinamica S.p.A
意大利迪普马公司
E4P4K - E07P4K - E5P4K - E10P4K
先导式电磁阀，防爆型电磁方向控制阀
1、型号及标注
"E**P4K-**/***/*/20*-*K5"
"E"--先导式
"*"--规格：4 = CETOP P05; 07 = CETOP 07; 5 = CETOP 08; 10 = CETOP 10
"*"--pmax = 320 bar (标准)省略; H = 高压型 (pmax = 420 bar) 不适于E10P4K
"P"--P = 板式安装；R = 安装面为 CETOP R05 规格(仅适于 E4 阀，不适于H高压型)
"4"--通路数目
"K"--防爆型EEx-d IIC-T5
"**"--功能：芯子和连接图类型(见表2.2)
"*"--阀芯控制(不需要则省略)：C = 主阀芯行程控制(不适于E10P4K); D = 主阀芯移动速度控制; G = 主阀芯行程和移动速度控制，不适于E10阀; PF = 带0,8阻尼器（P路）过渡板，安装在电磁阀下
"*"--先导控制：内部先导省略；E = 外部先导(阀芯形式为S2-S4-S7-S8 -必须选外部先导。仅C3选项时，方可选用内部先导)
"*"--泄漏：I = 内部泄漏 (外部泄漏省略。当回油管路存在较大背压时，建议选用外部泄漏)
"*"--单向阀，不需要则省略 (标准)：C3 = 带单向阀 P路安装，开启压力5 bar (仅适于E07P4K 和 E5P4K) 不适于高压H型
"20"--系列号 ：(序列号20-29外形及安装尺寸不变)
"*"--密封：N = 矿物油采用NBR密封(标准)；V = 特殊油采用FPM密封
"*"--线圈类型：D24 = 24 V 直流电源; AR110 = 110 V; AR230 = 230 V 交流电源(线圈内置桥式整流电路)
"K5"--带输出电缆的线圈提供导线安装装置

防爆型电磁方向控制阀
EEx-dIIC
序列号 20
MD1K CETOP 03
E4P4K CETOP P05
E07P4K CETOP 07
E5P4K CETOP 08
E10P4K CETOP 10
可堪孤馆闭春寒，杜鹃声里斜阳暮。 —— 秦观《踏莎行·郴州旅舍》
E5P4K-TA/D/I/20/V-D12K5迪普马电液换向阀
意大利迪普马 电液阀 换向阀 方向控制阀 方向阀 Duplomatic 电磁阀 防爆阀 液压阀
Duplomatic Oleodinamica S.p.A
意大利迪普马公司
---- 型号列举 ----
MD1K-S2/21N-D24K5
MD1K-S3/21N-D24K5
MD1K-S4/21N-D24K5
MD1K-TA/21N-D24K5
MD1K-TA002/21N-D24K5
MD1K-RK/21N-D24K5
MD1K-S1/21V-D24K5
MD1K-S2/21V-D24K5
MD1K-S3/21V-D24K5
MD1K-S4/21V-D24K5
MD1K-TA/21V-D24K5
MD1K-TA002/21V-D24K5
MD1K-RK/21V-D24K5

MD1K-S1/21N-AR24K5
MD1K-S2/21N-AR24K5
MD1K-S3/21N-AR24K5
MD1K-S4/21N-AR24K5
MD1K-TA/21N-AR24K5
MD1K-TA002/21N-AR24K5
MD1K-RK/21N-AR24K5
MD1K-S1/21V-AR24K5
MD1K-S2/21V-AR24K5
MD1K-S3/21V-AR24K5
MD1K-S4/21V-AR24K5
MD1K-TA/21V-AR24K5
MD1K-TA002/21V-AR24K5
MD1K-RK/21V-AR24K5

MD1K-S1/21N-D110K5
MD1K-S2/21N-D110K5
MD1K-S3/21N-D110K5
MD1K-S4/21N-D110K5
MD1K-TA/21N-D110K5
MD1K-TA002/21N-D110K5
MD1K-RK/21N-D110K5
MD1K-S1/21V-D110K5
MD1K-S2/21V-D110K5
MD1K-S3/21V-D110K5
MD1K-S4/21V-D110K5
MD1K-TA/21V-D110K5
MD1K-TA002/21V-D110K5
MD1K-RK/21V-D110K5

MD1K-S1/21N-AR110K5
MD1K-S2/21N-AR110K5
MD1K-S3/21N-AR110K5
MD1K-S4/21N-AR110K5
MD1K-TA/21N-AR110K5
MD1K-TA002/21N-AR110K5
MD1K-RK/21N-AR110K5
MD1K-S1/21V-AR110K5
MD1K-S2/21V-AR110K5
MD1K-S3/21V-AR110K5
MD1K-S4/21V-AR110K5
MD1K-TA/21V-AR110K5
MD1K-TA002/21V-AR110K5
MD1K-RK/21V-AR110K5

MD1K-S1/21N-AR230K5
MD1K-S2/21N-AR230K5
MD1K-S3/21N-AR230K5
MD1K-S4/21N-AR230K5
MD1K-TA/21N-AR230K5
MD1K-TA002/21N-AR230K5
MD1K-RK/21N-AR230K5
MD1K-S1/21V-AR230K5
MD1K-S2/21V-AR230K5
MD1K-S3/21V-AR230K5
MD1K-S4/21V-AR230K5
MD1K-TA/21V-AR230K5
MD1K-TA002/21V-AR230K5
MD1K-RK/21V-AR230K5
闺中少妇不知愁，春日凝妆上翠楼。 —— 王昌龄《闺怨》
E4P4K-TA/I/20/N-D12K5
E4P4K-TC/C/I/20/N-D12K5
E4P4K-S1/D/I/20/N-D12K5
E4P4K-TA/D/I/20/N-D12K5
E4P4K-RK/D/I/20/N-D12K5
E4P4K-TC/D/I/20/N-D12K5
E4P4K-S1/G/I/20/N-D12K5
E4P4K-TA/G/I/20/N-D12K5
E4P4K-RK/G/I/20/N-D12K5
E4P4K-TC/G/I/20/N-D12K5
E4P4K-S1/PF/I/20/N-D12K5
E4P4K-TA/PF/I/20/N-D12K5
E4P4K-RK/PF/I/20/N-D12K5
E4P4K-TC/PF/I/20/N-D12K5
E4P4K-S1/I/20/V-D12K5
E4P4K-TA/I/20/V-D12K5
E4P4K-RK/I/20/V-D12K5
E4P4K-TC/D/I/20/V-D12K5
E4P4K-S1/G/I/20/V-D12K5
E4P4K-TA/G/I/20/V-D12K5
E4P4K-RK/G/I/20/V-D12K5
E4P4K-TC/G/I/20/V-D12K5
E4P4K-S1/PF/I/20/V-D12K5
E4P4K-TA/PF/I/20/V-D12K5
E4P4K-RK/PF/I/20/V-D12K5
E4P4K-TC/PF/I/20/V-D12K5
E4P4K-S1/I/20/N-D24K5
E4P4K-TA/I/20/N-D24K5
E4P4K-RK/I/20/N-D24K5
E4P4K-TC/I/20/N-D24K5

E4P4K-S1/D/I/20/N-D110K5
E4P4K-TA/D/I/20/N-D110K5
E4P4K-RK/D/I/20/N-D110K5
E4P4K-TC/D/I/20/N-D110K5
E4P4K-S1/G/I/20/N-D110K5
E4P4K-TA/G/I/20/N-D110K5
E4P4K-RK/G/I/20/N-D110K5
E4P4K-TC/G/I/20/N-D110K5
E4P4K-S1/PF/I/20/N-D110K5

E4P4K-S1/I/20/N-AR110K5
E4P4K-TA/I/20/N-AR110K5
E4P4K-RK/I/20/N-AR110K5
E4P4K-TC/I/20/N-AR110K5
E4P4K-S1/C/I/20/N-AR110K5
E4P4K-TA/C/I/20/N-AR110K5
E4P4K-RK/C/I/20/N-AR110K5
E4P4K-TC/C/I/20/N-AR110K5
E4P4K-S1/D/I/20/N-AR110K5
E4P4K-TA/D/I/20/N-AR110K5
E4P4K-RK/D/I/20/N-AR110K5
E4P4K-TC/D/I/20/N-AR110K5
E4P4K-S1/G/I/20/N-AR110K5
E4P4K-TA/G/I/20/N-AR110K5
E4P4K-RK/G/I/20/N-AR110K5
E4P4K-TC/G/I/20/N-AR110K5
E4P4K-S1/PF/I/20/N-AR110K5
淮南秋雨夜，高斋闻雁来。 —— 韦应物《闻雁》
E07P4K-TA/I/20/N-D12K5
E07P4K-TC/C/I/20/N-D12K5
E07P4K-S1/D/I/20/N-D12K5
E07P4K-TA/D/I/20/N-D12K5
E07P4K-RK/D/I/20/N-D12K5
E07P4K-TC/D/I/20/N-D12K5
E07P4K-S1/G/I/20/N-D12K5
E07P4K-TA/G/I/20/N-D12K5
E07P4K-RK/G/I/20/N-D12K5
E07P4K-TC/G/I/20/N-D12K5
E07P4K-S1/PF/I/20/N-D12K5
E07P4K-TA/PF/I/20/N-D12K5
E07P4K-RK/PF/I/20/N-D12K5
E07P4K-TC/PF/I/20/N-D12K5
E07P4K-S1/I/20/V-D12K5
E07P4K-TA/I/20/V-D12K5
E07P4K-RK/I/20/V-D12K5
E07P4K-TC/D/I/20/V-D12K5
E07P4K-S1/G/I/20/V-D12K5
E07P4K-TA/G/I/20/V-D12K5
E07P4K-RK/G/I/20/V-D12K5
E07P4K-TC/G/I/20/V-D12K5
E07P4K-S1/PF/I/20/V-D12K5
E07P4K-TA/PF/I/20/V-D12K5
E07P4K-RK/PF/I/20/V-D12K5
E07P4K-TC/PF/I/20/V-D12K5
E07P4K-S1/I/20/N-D24K5
E07P4K-TA/I/20/N-D24K5
E07P4K-RK/I/20/N-D24K5

E07P4K-S1/D/I/20/N-D110K5
E07P4K-TA/D/I/20/N-D110K5
E07P4K-RK/D/I/20/N-D110K5
E07P4K-TC/D/I/20/N-D110K5
E07P4K-S1/G/I/20/N-D110K5
E07P4K-TA/G/I/20/N-D110K5
E07P4K-RK/G/I/20/N-D110K5
E07P4K-TC/G/I/20/N-D110K5
E07P4K-S1/PF/I/20/N-D110K5

E07P4K-S1/I/20/N-AR110K5
E07P4K-TA/I/20/N-AR110K5
E07P4K-RK/I/20/N-AR110K5
E07P4K-TC/I/20/N-AR110K5
E07P4K-S1/C/I/20/N-AR110K5
E07P4K-TA/C/I/20/N-AR110K5
E07P4K-RK/C/I/20/N-AR110K5
E07P4K-TC/C/I/20/N-AR110K5
E07P4K-S1/D/I/20/N-AR110K5
E07P4K-TA/D/I/20/N-AR110K5
E07P4K-RK/D/I/20/N-AR110K5
E07P4K-TC/D/I/20/N-AR110K5
E07P4K-S1/G/I/20/N-AR110K5
E07P4K-TA/G/I/20/N-AR110K5
E07P4K-RK/G/I/20/N-AR110K5
E07P4K-TC/G/I/20/N-AR110K5
打起黄莺儿，莫教枝上啼。 —— 金昌绪《春怨》
E5P4K-RK/C/I/20/N-D12K5
E5P4K-TC/C/I/20/N-D12K5
E5P4K-S1/D/I/20/N-D12K5
E5P4K-TA/D/I/20/N-D12K5
E5P4K-RK/D/I/20/N-D12K5
E5P4K-TC/D/I/20/N-D12K5
E5P4K-S1/G/I/20/N-D12K5
E5P4K-TA/G/I/20/N-D12K5
E5P4K-RK/G/I/20/N-D12K5
E5P4K-TC/G/I/20/N-D12K5
E5P4K-S1/PF/I/20/N-D12K5
E5P4K-TA/PF/I/20/N-D12K5
E5P4K-RK/PF/I/20/N-D12K5
E5P4K-TC/PF/I/20/N-D12K5
E5P4K-S1/I/20/V-D12K5
E5P4K-TA/I/20/V-D12K5
E5P4K-RK/I/20/V-D12K5
E5P4K-RK/D/I/20/V-D12K5
E5P4K-TC/D/I/20/V-D12K5
E5P4K-S1/G/I/20/V-D12K5
E5P4K-TA/G/I/20/V-D12K5
E5P4K-RK/G/I/20/V-D12K5
E5P4K-TC/G/I/20/V-D12K5
E5P4K-S1/PF/I/20/V-D12K5
E5P4K-TA/PF/I/20/V-D12K5
E5P4K-RK/PF/I/20/V-D12K5
E5P4K-TC/PF/I/20/V-D12K5
E5P4K-S1/I/20/N-D24K5
E5P4K-TA/I/20/N-D24K5
E5P4K-RK/I/20/N-D24K5

E5P4K-TC/C/I/20/N-D110K5
E5P4K-S1/D/I/20/N-D110K5
E5P4K-TA/D/I/20/N-D110K5
E5P4K-RK/D/I/20/N-D110K5
E5P4K-TC/D/I/20/N-D110K5
E5P4K-S1/G/I/20/N-D110K5
E5P4K-TA/G/I/20/N-D110K5
E5P4K-RK/G/I/20/N-D110K5
E5P4K-TC/G/I/20/N-D110K5

E5P4K-S1/I/20/N-AR110K5
E5P4K-TA/I/20/N-AR110K5
E5P4K-RK/I/20/N-AR110K5
E5P4K-TC/I/20/N-AR110K5
E5P4K-S1/C/I/20/N-AR110K5
E5P4K-TA/C/I/20/N-AR110K5
E5P4K-RK/C/I/20/N-AR110K5
E5P4K-TC/C/I/20/N-AR110K5
E5P4K-S1/D/I/20/N-AR110K5
E5P4K-TA/D/I/20/N-AR110K5
E5P4K-RK/D/I/20/N-AR110K5
E5P4K-TC/D/I/20/N-AR110K5
E5P4K-S1/G/I/20/N-AR110K5
E5P4K-TA/G/I/20/N-AR110K5
E5P4K-RK/G/I/20/N-AR110K5
E5P4K-TC/G/I/20/N-AR110K5
……
