产品名称：36芯室外层绞式铠装光缆
型号︰
GYTA-36B1
品牌︰
汉信
原产地︰
中国
产品描述 DeSCRJPTion
GYTA 光缆的结构是将 250μm 光纤套入高模量材制成的松套管中，松套管内填充防水化合物。缆芯的中心是一根金属加强芯，对于某些芯数的光缆来说，金属加强芯外还需挤上一层聚乙烯（PE）。松套管（和填充绳）围绕中心加强芯绞合成紧凑和圆形的缆芯，缆芯内的缝隙充以阻水填充物。涂塑铝带（PL）纵包后挤制聚乙烯护套成缆。
The fibers, 250μm,are
POSTTTIONed in a loose tube made of a high modulus plastic. The tubes are
filled with a water-resistant filling compound. A steel wire, sometimes
sheathed with polyethylene (PE) for cable with high fiber count, locates in
the center of core as a metallic strength member. Tubes (and fillers) are
stranded around the strength member into a compact and circular cable core.
An Aluminum Polyethylene Laminate (APL) is applied around the cable core,
which is filled with the filling compound to protect it from water ingress.
Then, the cable is completed with a PE sheath.
·产品特点 Characteristics
· 具有很好的机械性能和温度特性
· 松套管材料本身具有良好的耐水性能和较高的强度
· 管内充以特种油膏，对光纤进行了关键性保护
· 特别设计的紧密的光缆结构，有效防止套管回缩
· PE护套具有很好的抗紫外辐射性能
· 采用下列措施来确保光缆的防水性能：
- 单根钢丝中心加强芯
- 松套管内填充特种防水化合物
- 完全缆芯填充
- 涂塑铝带（APL）防潮层
·产品标准 Standards
GYTA 光缆符合 YD/T 901-2001 和 IEC 60794-1 标准
·光学特性 Optical Characteristics
G.652
G.655
50/125μm
62.5/125μm
衰减Attenuation
(+20℃)
@850nm
≤3.0
dB/km
≤3.0
dB/km
@1300nm
≤1.0
dB/km
≤1.0
dB/km
@1310nm
≤0.36
dB/km
≤0.40
dB/km
@1550nm
≤0.22
dB/km
≤0.23dB/km
带宽(A级)Bandwidth (Class A)
@850nm
≥500
MHz·km
≥200
MHz·km
@1300nm
≥1000
MHz·km
≥600
MHz·km
数值孔径Numerical
Aperture
0.200±0.015NA
0.275±0.015NA
光缆截止波长Cable
Cut-off Wavelength λcc
≤1260nm
≤1480nm
光缆型号Cable
Type
光纤数Fiber
Count
套管数
Tubes
填充绳数Fillers
光缆直径
Cable Diameter
mm
光缆重量Cable
Weight kg/km
允许拉伸力
Tensile Strength
长期/短期
Long/Short Term N
允许压扁力Crush
Resistance
长期/短期
Long/Short Term
N/100mm
弯曲半径
Bending Radius
静态/动态
Static
mm
GYTA-2~6芯
2~6
1
4
9.7
90
600/1500
300/1000
10D/20D
GYTA-8~12芯
8~12
2
3
9.7
90
600/1500
300/1000
10D/20D
GYTA-14~18芯
14~18
3
2
9.7
90
600/1500
300/1000
10D/20D
GYTA-20~24芯
20~24
4
1
9.7
90
600/1500
300/1000
10D/20D
GYTA-26~30芯
26~30
5
0
9.7
90
600/1500
300/1000
10D/20D
GYTA-32~36芯
32~36
6
0
10.2
104
1000/3000
300/1000
10D/20D
GYTA-38~48芯
38~48
4
1
11.0
117
1000/3000
300/1000
10D/20D
GYTA-50~60芯
50~60
5
0
11.0
117
1000/3000
300/1000
10D/20D
GYTA-62~72芯
62~72
6
0
11.5
126
1000/3000
300/1000
10D/20D
GYTA-74~84芯
74~84
7
1
13.4
154
1000/3000
300/1000
10D/20D
GYTA-86~96芯
86~96
8
0
13.4
154
1000/3000
300/1000
10D/20D
GYTA-98~108芯
98~108
9
1
14.8
185
1000/3000
300/1000
10D/20D
GYTA-110~120芯
110~120
10
0
14.8
185
1000/3000
300/1000
10D/20D
GYTA-122~132芯
122~132
11
1
16.9
228
1000/3000
300/1000
10D/20D
GYTA-134~144芯
134~144
12
0
16.9
228
1000/3000
300/1000
10D/20D
GYTA-146~216芯
146~216
16.9
233
1000/3000
300/1000
10D/20D
储存、使用温度: -40℃ 至 +
70℃
· Good mechanical and
temperature performance
· High strength looes tube that
is hydrolysis resistant
· Special tube filling compound
ensure a critical protection of fiber
· Specially designed compact
structure is good at preventing loose tubes from shrinking
· PE sheath protects cable from
ultraviolet radiation
· The following measures are
taken to ensure the cable watertight:
- Steel wire used as the central strength member
- Loose tube filling compound
- 100% cable core filling
- APL moisture barrier
GYTA cable complies with
Standard YD/T 901-2001as well as IEC 60794-1.
·结构参数 Technical Parameters
/Dynamic
Storage/Operating Temperature : -40℃ to + 70℃
