? Place the insulation tub on the drain line of the shield and connect

it to the terminal.

? Tighten the screw and then check visually to see if there is

insulation between the cores.

? Connect the cores to pins 1 to 4.三菱触摸屏 西门子触摸屏 台达触摸屏

* When tightening the screws, use the dedicated XW4Z-00B

Screwdriver that matches with the screw-slot dimensions.

(4) Inserting Pin Block三菱触摸屏 西门子触摸屏 台达触摸屏

? Mount the cover to the pin block so that the triangle mark on the pin

block will coincide with the triangle mark on the cover.

? If the cover is used for an Angled model, the relationship between

the POSTTTION of the polarity key on the engaged side and cable

connection direction will be determined by the direction in which

the POSTTTIONing key is inserted into the cover, which can be rotated

by 90°.三菱触摸屏 西门子触摸屏 台达触摸屏

? Fully insert the POSTTTIONing key until the POSTTTIONing key is hidden by

the casing.

Screw-on Connectors

Pin Block Pin Clamp三菱触摸屏 西门子触摸屏 台达触摸屏

Key groove Key groove

Key XS5C use XS5G use

6±0.5三菱触摸屏 西门子触摸屏 台达触摸屏

I

? Align the triangular marks on the pin block and cover and insert the

pin block into the cover.

? Press them together firmly (0.39 to 0.49 N·m) until the pin block

does not come out of the cover.

(5) Mounting Cap三菱触摸屏 西门子触摸屏 台达触摸屏

? After mounting the cover to the pin block and the cover snaps into

place, tighten the cap securely by hand within a torque of 0.39 and

0.49 N·m.

Note: If the cap is not tighten securely enough, the degree of

protection (IP67) may not be maintained or vibration may

cause the cap to become loose. Do not tighten the cap with

pliers or similar tools; they may damage the cap.

? After fully tightening the cap, length A should be approximately one

of the following according to the cable external diameter and the

Connector model.三菱触摸屏 西门子触摸屏 台达触摸屏

(6) After Assembly三菱触摸屏 西门子触摸屏 台达触摸屏

? Confirm the insulation between cores after completing assembly.

Recommended Cables三菱触摸屏 西门子触摸屏 台达触摸屏

When connecting a commercially available cable to a connector

assembly, use a cable with an outside diameter of 3 to 6 mm and core

sizes of 0.18 to 0.75 mm2 for crimping connectors and 0.5 mm2

三菱触摸屏 西门子触摸屏 台达触摸屏
