| 型号 |
适用导线外径 φmm |
L1 | L2 | L3 | L4 | M |
| JGW-1 | 75-84 | 120 | 150 | 90 | 114 | 2-M12 |
| JGW-2 | 85-94 | 130 | 160 | 80 | 124 | 2-M14 |
| JGW-3 | 95-104 | 140 | 175 | 80 | 138 | 2-M14 |
| JGW-4 | 105-114 | 150 | 185 | 80 | 150 | 2-M14 |
| JGW-5 | 115-124 | 160 | 195 | 90 | 160 | 2-M14 |
| JGW-6 | 125-134 | 175 | 215 | 90 | 175 | 2-M16 |
| JGW-7 | 135-146 | 190 | 230 | 100 | 195 | 2-M16 |
| JGW-8 | 140-165 | 210 | 265 | 100 | 205 |
2-M16 |
| 型号 |
适用导线外径 φmm |
L1 | L2 | L3 | L4 | M |
| JGW(2)-1 | 40-50 | 140 | 174 | 60 | 60 | 2-M12 |
| JGW(2)-2 | 50-60 | 160 | 194 | 60 | 70 | 2-M12 |
| JGW(2)-3 | 60-70 | 185 | 219 | 70 | 82 | 2-M12 |
| JGW(2)-4 | 70-80 | 205 | 239 | 70 | 92 | 2-M12 |
| JGW(2)-5 | 80-90 | 225 | 259 | 80 | 102 | 2-M12 |
| JGW(2)-6 | 90-100 | 245 | 279 | 80 | 112 | 2-M12 |
| JGW(2)-7 | 100-110 | 270 | 304 | 90 | 122 | 2-M16 |
| JGW(2)-8 | 110-120 | 290 | 324 | 90 | 132 | 2-M16 |
| JGW(2)-9 | 120-130 | 310 | 344 | 90 | 142 | 2-M16 |
| JGW(2)-10 | 130-140 | 330 | 364 | 100 | 152 | 2-M16 |
| JGW(2)-11 | 140-1580 | 350 | 384 | 100 | 162 | 2-M16 |
