订货须知BXX52-2防爆电源插座箱
Scope of application:
1、适用于爆炸性气体环境1区、2区；
1, applicable to the 2 District, 1 District, explosive gas environment;
2、适用于IIA、IIB级爆炸性气体环境；
2, suitable for IIA, IIB explosive gas environment;
3、适用于温度组别为T1-T6的环境；
3, apply to the temperature classes for T1-T6 environment;
4、适用于石油采炼、储存、化工、医药、军工及军事设施等爆炸性危险环境;
4, applicable to the petroleum production and refining, storage, chemical, pharmaceutical, military and military facilities and other explosive dangerous environment;
5、主要用于临时作业或移动作业的电源分配；
5, mainly used for power distribution of temporary work or move operation;
6、本产品为多壳体拼装结构。
6, this product is multi shell assembling structure.
产品特点BXX52-2防爆电源插座箱
Product features
1、外壳采用铝合金高压铸造成型，表面经抛丸后高压静电喷塑；
1, the shell adopts aluminium alloy high pressure casting forming, surface of high-pressure electrostatic pensu after blast;
2、采用模块化设计，各回路可以自由组合，带总开关产品内装高分断小型断路器或塑壳断路器；
2, the use of modular design, the circuit can be combined freely, with a total switch products installed MCB or mccb;
3、可根据用户要求增加漏电、过载、短路保护等功能；
3, can increase the leakage, overload, short circuit protection function according to user requirements;
4、多种规格的插座可供选择；
Socket 4, a variety of specifications are available;
5、可根据用户要求特殊制造；
5, according to user requirements special manufacturing;
∈产品性能特点：
Performance characteristics of ∈ products:
1、防爆电源插座箱为复合型防爆结构。元件腔采用隔爆型防爆结构，进、出线腔采用增安型防爆结构。各腔体之间采用模块式组合，隔爆腔之间互不相通，减小了单个腔体的净容积，从而消除了爆炸压力重迭，增强了产品的防爆性能；各回路可以****选择、拼装；体积小，整齐、美观，占用安装现场空间较少；重量轻，安装、维护方便。
1, explosion proof power socket box for the explosion-proof structure of the compound. The element cavity flameproof explosion-proof structure, into the outlet chamber, with increased safety explosion-proof structure. The cavity between the modular combination, between the flame-proof cavity are not communicated with each other, reducing the net volume of single cavity, thereby eliminating the explosion pressure overlap, enhanced the explosion-proof performance of products; the loop can be * * * * selection, assembly; small, neat, beautiful, occupy less space on the site installation; light weight, installation, easy maintenance.
2、本系列产品为铸铝合金外壳，铝合金为ZL102符合国家标准。产品壳体采用燃油、高温、恒温一次压铸成型工艺，压铸产品表面光滑，外形美观大方，金属结构致密度高，外壳结构内部无气泡、无砂眼，抗冲击性能增强(铸铝合金的抗拉强度为原来的近2倍，硬度为原来的近1.5倍，密度比原来也有所增加)，产品外壳防爆性能好，产品上有压制的永久性防爆标志。
2, this series of products for the enclosure is made of casting aluminum alloy, aluminum alloy in line with national standards for ZL102. The shell of the product by a casting process of fuel, high temperature, constant temperature, casting products smooth surface, beautiful appearance, metal structure, high density, no bubble, no blisters shell structure, enhance the anti impact properties (tensile strength of cast aluminum alloy is nearly 2 times, the hardness is nearly 1.5 times, the original density than the original also increased), product shell good explosion proof, explosion-proof products are pressed on the permanent sign.
3、产品表面通过高速抛丸等系列工艺处理后，采用先进的高压静电喷塑工艺进行表面喷塑，并经全自动恒温热处理流水线工艺后，壳体表面形成的塑层附着力强，不易脱落，有效达到保护壳体的目的，提高了产品的防腐能力，且远优于喷漆工艺。
3, the product surface by high-speed blast series process, using high voltage electrostatic spray process advanced surface spray, and the automatic constant temperature heat treatment process, the formation of surface of shell plastic layer adhesion, not easy to fall off, effectively protect the housing purposes, improve the ability of anti-corrosion products, and far better than the painting process.
4、隔爆型防爆结构的隔爆面满足GB3836-2000国家标准，精度达6.3μm。
4, flameproof explosion-proof structure of flameproof surface can meet the national standard GB3836-2000, precision is up to 6.3 μ M
5、产品外表面颜色为灰色，同时还有苹果绿、白色、蓝色、军绿色等多种颜色可供用户选择，也可按用户要求制作。
5, the product surface color to gray, and apple green, white, blue, green and other colors for customers to choose, also can be made according to user requirements.
6、所有外露紧固件均采用不锈钢材质。
6, all the exposed fastening pieces are made of stainless steel material.
7、电缆进出线方向，可根据用户要求做成上进上出、下进下出、上进下出、下进上出等多种形式。
7, a cable inlet and outlet direction, can be made according to user requirements on the mobility, lower in and out, under the upper lower, upper and other forms.
8、进出线口通常采用管螺纹，配置电缆夹紧密封装置；也可根据用户现场要求，制成公制螺纹、NPT等螺纹形式。
8, the inlet and outlet usually adopts the pipe thread, configuration cable clamping sealing device; can also be based on user requirements at the scene, made of NPT metric thread, thread form.
9、钢管、电缆布线均可。
9, pipe, cable wiring.
10、配电箱内部导线采用OT接线端子冷压接，并穿有套管进行绝缘处理，接线端子采用专用带防松瓦垫紧固，确保电气性能的稳定性，接线端子上有明确的进出线编号或标识。
10, the internal wire distribution box with OT wiring terminal cold pressure welding, and wear casing insulation treatment, terminals with special anti sunwar mat fastening, ensure the stability of electrical performance, a number of clear out line or labeling terminals.
11、配电箱内装主要元件为正宗施耐德产品，(开关)小型断路器为C65N系列(具有过载及短路保护功能)；交流接触器为LC1系列，热继电器为LR2系列。其余元件如：指示灯、按钮、仪表等元件，为我公司特制防爆元件，防爆性能及电气性能可靠。
11, power distribution box main components for the authentic Schneider products, (switch) for C65N series miniature circuit breaker (with overload and short circuit protection function); for LC1 series AC contactor, thermal relay LR2 series. Other elements such as: lights, buttons, instrumentation and other components, as our special explosion-proof component, explosion-proof performance and reliable electrical performance.
12、配电箱内装元件、支路数可根据用户要求配置；户外的产品可根据用户要求配置防雨罩。
12, power distribution box components, number of branches can be configured according to user requirements; outdoor products can be configured according to user requirements rain cover.
13、配电箱安装方式一般为挂式，特殊要求时可做成立式、座式或配电柜式。
13, distribution box installed by hanging, special requirements can be made into a vertical, seat type or power distribution cabinet.
14、电缆配置方式为：动力箱：输入3P+N+PE/输出3P+N+PE
14, the cable configuration mode: the power box: 3P+N+PE/ input output 3P+N+PE
照明箱：输入3P+N+PE/输出1P+N+PE
Lighting box: 3P+N+PE/ input output 1P+N+PE
15、本系列产品经铸造、加工、装配、检验等十余道工序，产品检验合格后才允许包装出厂。
15, this series of products by casting, machining, assembly, testing and other more than ten processes, products after passing inspection allowed packaging factory.
16、本系列产品出厂时，随机配有《使用说明书》、《保险卡》、《出厂合格证》、特殊元件的《使用说明书》等技术文件。
16, this series of products, random equipped with "instructions for use", "insurance card", "certificate", special components "instructions for use" and other technical documents.
17、本系列产品为专用木箱包装，并严格按相关国家标准要求进行包装出厂。

17, the series of products are the special wooden box packaging, and in strict accordance with the relevant national standards and requirements for packaging factory.
