赛特BAOTE蓄电池BT-HSE-90-12 特性90ah
赛特BAOTE蓄电池BT-HSE-90-12 特性90ah
使用说明
1、蓄电池的联接
● 容量不同、性能不同、生产厂家不同的蓄电池不可连接在一起使用。
● 实际容量相同的蓄电池或蓄电池组方可串联使用。
● 实际电压相同的蓄电池或蓄电池组方可并联使用。
● 蓄电池组连接和引出请用合适的导线。
● 连接和拆卸时务必切断电源,否则会触电甚至爆炸的危险。
● 正负极不得接反或短路,否则会使蓄电池严重受损,甚至发生爆炸。
● 连接部件应锁紧,防止产生火花;若接触面被氧化,可用苏打水清洗。
● 新安装的蓄电池组在使用前应进行72小时浮充充电使蓄电池组内部电量均衡,方可进行测试或使用。
2、蓄电池的充放电
● 浮充使用时充电参数的设置
BAOTE赛特/铅酸免维护蓄电池(北京)办事处
销售经理:13671285773
客服专线:010-57231386
客服Q Q:441873332
能帮到您的,我们会竭尽全力!!!
|
系列 |
型号 |
浮充电压 |
最大浮充电流 |
单格温度补偿系数 |
|
AGM系列 |
12V系列 |
2.27 ~2.30V/cell |
0.25C |
-3mV/℃ |
● 循环使用时充电参数的设置
|
系列 |
型号 |
均充电压 |
最大均充电流 |
单格温度补偿系数 |
|
AGM系列 |
12V系列 |
2.35 ~2.40V/cell |
0.25C |
-5mV/℃ |
● 放电电流与放电终止电压
Battery - heavy and brittle shell, handling should be handled with care, strictly tumbling and fell and storage battery, and do not pay attention to the terminal force.
The battery should be stored or installed in the dry and ventilated place, avoid direct sunlight, should keep away from heat and easy to produce the spark place.
The battery should be stored before the full charge state, are not allowed to discharge after storage.
The battery should be stored at 0 to 30 DEG C environment, storage battery should be every three months should be a supplement of electricity, the storage time
Longer than one year, otherwise the battery capacity and life will be reduced.
Matters needing attention:
The battery charged the factory, not to remove the battery to avoid danger, if the battery casing damage and into contact with the acid solution, rinse immediately with plenty of water, if necessary, consult a doctor immediately.
Can not the battery placed in the sealed environment, otherwise there will be danger of explosion.
Can not use organic solvent to clean the battery, otherwise it will damage the shell.
The only battery series can obtain high voltage, use insulated tools should be installed, to prevent electric shock.
Tighten the nut - should be installed, to prevent the charge and discharge spark or explosion.
The battery can not be inverted, otherwise there will be leakage of electrolyte.
The termination of life - when the battery should be properly handled, abandon the pollution of the environment.
This is a set of sales, installation, maintenance services in one company, efficient working methods and good business ethics seriously treat every customer, really let each customer without any menace from the rear, your satisfaction is our greatest pursuit!
|
放电电流 |
I≥1.0C |
0.2C≤I≤1C |
0.01C≤I≤0.2C |
0.004C≤I≤0.01C |
I≤0.004C |
|
放电终止电压 |
1.6V/cell |
1.7V/cell |
1.8V/cell |
1.85V/cell |
1.9V/cell |
备注:“C”表示额定容量
3、搬运、存储
● 蓄电池重且外壳脆,搬运时应轻拿轻放,严禁翻滚和摔蓄电电池,同时注意不要使端子受外力。
● 蓄电池应储存或安装于干燥通风的地方,避免阳光直射,应远离热源及易产生火花的地方。
● 蓄电池存放前应为满荷电状态,不允许放电后存放。
● 蓄电池应在0℃~30℃的环境下储存,存放的蓄电池应每三个月应进行一次补充电,存放时间最
长不能超过一年,否则电池容量及寿命将会减小。
注意事项:
● 蓄电池荷电出厂,不得试图拆卸蓄电池以避免发生危险,如不慎使蓄电池壳体破损而接触到酸液,请立即用大量清水冲洗,必要时,请立即就医。
● 不能将蓄电池放置于密封环境使用,否则会有爆炸的危险。
● 不能使用有机溶剂清洁蓄电池,否则会损伤壳体。
● 多只蓄电池串联可获得高电压,安装时应该使用绝缘工具,防止电击。
● 安装时应拧紧螺母,以防止充放电时产生火花甚至爆炸。
● 蓄电池不可倒置使用,否则会有电解液漏出。
● 蓄电池寿命终止时,应妥善处理,随意遗弃会造成环境污染。
本是一家以集销售、安装、维修服务于一体的公司,以高效率的工作方式及良好的商业道德认真对待每一位客户,真正让每一位客户无任何后顾之忧,让您满意是我们最大的追求!
