DJYPV,DJYPVP22计算机电缆
低烟无卤阻燃计算机电缆结构参数表
序号 对数
×
每对芯数
×
标称截面 电缆最大外径
WZR-DJYPE
WZR-DJYJPE
WZR-DJFYJPE WZR-DJYP2E
WZR-DJYJP2E
WZR-DJFYJP2E WZR-DJYP2EP2
WZR-DJYJP2EP2
WZR-DJFYJP2EP2 WZR-DJYP3E
WZR-DJYJP3E
WZR-DJFYJP3E WZR-DJYP3EA53
WZR-DJYJP3EA53
WZR-DJFYJP3EA53 WZR-DJYPE22
WZR-DJYJPE22
WZR-DJFYJPE22 WZR-DJYPEP
WZR-DJYJPEP
WZR-DJFYJPEP
1 1×2×0.75 8.4 8.4 9.3 8.4 10.3 11.6 9.5
2 2×2×0.75 14.8 14.8 15.7 14.8 16.7 18.0 15.9
3 3×2×0.75 15.6 15.6 16.5 15.6 17.5 18.8 16.7
4 4×2×0.75 17.0 17.0 17.9 17.0 18.9 20.2 18.1
5 5×2×0.75 18.8 18.8 19.7 18.8 20.7 22.0 19.9
6 6×2×0.75 21.2 21.2 22.1 21.2 23.1 24.4 22.3
7 7×2×0.75 21.2 21.2 22.1 21.2 23.1 24.4 22.3
8 8×2×0.75 22.2 22.2 23.1 22.2 24.1 25.4 23.3
9 9×2×0.75 26.0 26.0 26.9 26.0 27.9 29.2 27.3
10 10×2×0.75 26.0 26.0 26.9 26.0 27.9 29.2 27.3
11 12×2×0.75 27.1 27.1 27.9 27.1 28.9 30.2 28.3
12 14×2×0.75 28.4 28.4 29.3 28.4 30.3 31.6 29.7
13 16×2×0.75 30.4 30.4 31.3 30.4 32.3 33.6 31.7
14 19×2×0.75 32.0 32.0 32.9 32.0 33.9 35.2 33.3
15 24×2×0.75 37.8 37.8 37.8 37.8 38.8 41.0 39.1
15 1×3×0.75 8.8 8.8 9.7 8.8 10.7 12.0 9.9
16 3×3×0.75 16.5 16.5 17.4 16.5 18.4 19.7 17.6
17 4×3×0.75 18.2 18.2 19.1 18.2 20.1 21.4 19.3
18 5×3×0.75 19.9 19.9 20.8 19.9 21.8 23.1 21.0
19 6×3×0.75 22.0 22.0 22.9 22.0 23.9 25.2 23.3
20 7×3×0.75 22.0 22.0 22.9 22.0 23.9 25.2 23.3
21 8×3×0.75 23.7 23.7 24.6 23.7 25.6 26.9 25.0
22 10×3×0.75 28.2 28.2 29.1 28.2 30.1 31.4 29.3
23 12×3×0.75 29.1 29.1 30.0 29.1 31.0 32.3 30.3
24 14×3×0.75 30.6 30.6 31.5 30.6 32.5 33.8 31.9
25 1×2×1.0 8.8 8.8 9.7 8.8 10.7 12.0 9.9
26 2×2×1.0 15.8 15.8 16.7 15.8 17.7 19.0 16.9
27 3×2×1.0 16.5 16.5 17.4 16.5 18.4 19.7 17.9
28 4×2×1.0 18.2 18.2 19.1 18.2 20.1 21.4 19.3
29 5×2×1.0 19.9 19.9 20.8 19.9 21.8 23.1 21.0
30 6×2×1.0 22.0 22.0 22.9 22.0 23.9 25.2 23.3
31 7×2×1.0 22.0 22.0 22.9 22.0 23.9 25.2 23.3
32 8×2×1.0 23.7 23.7 24.6 23.7 25.6 26.9 25.0
33 9×2×1.0 28.2 28.2 29.1 28.2 30.1 31.4 29.3
34 10×2×1.0 28.2 28.2 29.1 28.2 30.1 31.4 29.3
35 12×2×1.0 29.1 29.1 30.0 29.1 31.0 32.3 30.3
36 14×2×1.0 30.6 30.6 31.5 30.6 32.5 33.8 31.9
37 16×2×1.0 32.7 32.7 33.6 32.7 34.6 35.9 34.0
38 19×2×1.0 34.8 34.8 35.7 34.8 36.7 37.6 35.7
24×2×1.0 40.8 40.8 41.7 40.8 42.7 44.0 42.1
39 1×3×1.0 9.2 9.2 10.1 9.2 11.1 12.4 10.3
40 3×3×1.0 18.0 18.0 18.9 18.0 19.9 20.8 18.7
41 4×3×1.0 19.6 19.6 20.5 19.6 21.5 22.4 20.3
42 5×3×1.0 21.3 21.3 22.2 21.3 23.2 24.5 22.6
43 6×3×1.0 23.2 23.2 24.1 23.2 25.1 26.4 24.5
44 7×3×1.0 23.2 23.2 24.1 23.2 25.1 26.4 24.5
45 8×3×1.0 25.1 25.1 26.0 25.1 27.0 28.3 26.4
46 10×3×1.0 29.8 29.8 30.7 29.8 31.7 33.0 31.1
47 12×3×1.0 30.8 30.8 31.7 30.8 32.7 34.0 32.1
