OM-CP-QUADRTD-CERT

4通道温度数据记录器
NOMAD系列成员
OM-CP-QUADRTD
5年保修
4通道温度数据记录器
NOMAD系列成员
OM-CP-QUADRTD:4通道温度数据记录器lt;brgt;NOMAD系列成员

om-cp-quadrtd
100pt RTD输入
实时操作
0.01°C分辨率
可编程的开始时间
通过软件用户校准


CP的OM quadrtd温度记录器是一个4通道，电池供电，的，基于RTD温度记录仪的精度。这是对所有在一个紧凑，便携，易于使用的设备，将测量和记录的21845测量通过通道。在存储介质是一个非挥发性固态存储器，提供的数据安全，即使电池discharged变成。设备可以直接从您的开始和停止的计算机和它的小尺寸允许它适合几乎任何地方。CP的OM quadrtd使数据检索的快速和容易。它简单的插到空虚的COM端口和一个易于使用的WINOOWs软件没有休息。
把你的软件的WINOOWs PC变成一个实时长条图表记录仪。可以印刷在数据格式和图形或tabular可以出口到Microsoft Excel或文本文件。

规格：
TEMPERATURE
Input Type: 100Pt RTD, α = 0.00385
Measurement Range: -200 to 850°C (-328 to 1562°F)
Resolution: 0.01°C
Calibrated Accuracy: ±0.1°C @ 25°C ambient
(does not include RTD error)
Specified Accuracy Range:
-200 to 850°C (-328 to 1562°F)

RESISTANCE
Nominal Range: 0 to 500Ω
Resolution: 0.001
Calibrated Accuracy: ±0.03 @ 25°C ambient
Specified Accuracy Range: 0 to 500Ω
Channels: 4
Input Connection: Removable screw terminal;
2, 3, or 4 wire interface
Start Time: Start time and date
are programmable through software
Real Time Recording: Device may be used with PC
to monitor and record data in real time
Memory: 21,845 readings per channel
Recording Interval: 2 sec to 12 hours,
able through software
Calibration Date: Automatically recorded within device
to alert user when calibration is required
Temperature Calibration: Digital calibration is available in software
Power: 9 V lithium battery included; 120 Vac power optional
Battery Life: 1 year typical
Data Format: Date and time stamped, °C, °F, °K, °R,
Time Accuracy: ±1 minute per month at 20°C
(when RS-232 port not in use)
Computer Interface: PC serial, RS-232C COM or USB
(interface cable required) 2400 baud
Software:
WINOOWs XP SP3/Vista/7 and 8 (32-bit and 64-bit)
Operating Environment: -20 to 60°C (-4 to 140°F)
0 to 95% RH non-condensing
Dimensions:
89 H x 111 W x 26 mm D
(3.5 x 4.4 x 1.0")
Weight: 370 g (13 oz)
Material: Black anodized aluminum
