OM-CP-THERMOVAULT

烤箱温度数据记录器
OM-CP-THERMOVAULT
5年保修
烤箱温度数据记录器
OM-CP-THERMOVAULT:烤箱温度数据记录器

OM-CP-THERMOVAULT
单通道热电偶输入
可编程的开始时间；立即或日期/时间
小尺寸
短的热分析事件记录
该OM-CP-THERMOVAULT是绝热的，电池供电的，的，用于热分析的事件数据记录器。该装置可以用来记录烤箱内的温度后下载到电脑上。这一结构紧凑，便携，易于使用的设备，将测量和记录多达500000个温度测量。是的OM-CP-THERMOVAULT提出降低成本和性能的重大飞跃。实时时钟确保所有数据的时间和日期戳。存储介质是非挥发性固态存储器，提供的数据安全，即使电池已出院。它的小尺寸使得它几乎可以满足任何地方。数据检索是简单的。插入一个可用的COM端口和易于使用的软件是否休息。该软件将你的电脑变成一个真正的时间的长条图表记录仪。数据可以打印图形或表格的格式，可以导出到一个文本文件或微软。

规格：

Thermocouple Connection:
Fixed 2 POSTTTION screw terminal
Cold Junction Compensation: automatic
Accuracy*: (based on internal channel at uniform 20°C): J,K,T,E,N: ±0.5°C
R,S,B: ±2.0°C
Resolution: J,K,T,E,N: 0.1°C
R,S,B: 0.5°C
Temperature Measurement Range:
Type J:-210 to 760°C
K:-270 to 1370°C
T:-270 to 400°C
E:-270 to 980°C
R:-50 to 1760°C
S:-50 to 1760°C
B:50 to 1820°C
N:-270 to 1300°C
Memory: 500,000 readings; software configurable memory wrap;
250,000 readings in multiple start/stop mode
Recording Interval: 1 second to 24 hours able in software
Start Time: Start time and date are programmable through software
Power: 3.6 V lithium battery included
Battery Life: 1 year typical
Data Format: Date and time stamped,
°C, °F, K, °R, mV
Computer Interface: USB (interface cable required;
115,200 baud
Software: XP SP3/Vista/7 and 8 (32-bit and 64-bit)

Operating Environment for Internal Data Logger:
-40 to +80°C (-40 to 176°F) 0 to 95% RH non-condensing
Operating Environment for OM-CP-THERMOVAULT System: -40 to +400°C (-40 to 752°F)
0 to 95% RH non-condensing

Temperature Versus Logger Duration Time

*Assuming logger box is inititally at 25°C

Dimensions: 64 H x 129 L x 113 mm D (2.5 x 5.1 x 4.5")
Weight: 1.59 kg (3.5 lbs)
Enclosure (Thermal Box): 304 stainless steel with PTFE insulation
Enclosure (Logger): ABS Plastic

产品型号 产品描述

OM-CP-THERMOVAULT Oven temperature datalogger

OM-CP-THERMOVAULT-CERT Oven temperature datalogger with NIST calibration certifcate

OM-CP-IFC200 WINOOWs software and 3.7 m (12') USB interface cable

OM-CP-BAT105 Replacement 3.6 V lithium battery

OM-CP-THERMOVAULT
