商品品牌：安捷伦
商品型号：N5245A
商品成色：八成新以上
商品价格：面议或电议
商品详情：
主要特性与技术指标
10 MHz 到 50 GHz
2 端口或 4 端口，具有两个内置信号源
126 dB 系统动态范围和 129 dB 接收机动态范围、32,001 点、32 通道、5 MHz IF 带宽
高输出功率（+16 dBm）、低谐波（-60 dBc）和宽功率扫描范围（41 dB）
最佳动态精度――在接收机端使用 0.1 dB 压缩和 +15 dBm 输入功率
在 10 Hz IFBW 时仅有 -111 dBm 的低本底噪声
描述
全球最广泛的单次连接测量应用软件
PNA-X 网络分析仪是全球功能最全、最灵活的单次连接微波测试引擎，可测量放大器、混频器和频率转换器等有源器件。目前它提供以下五种频率型号供您选择：13.5、26.5、43.5、50 和 67 GHz，可满足您特定的器件测试需求。PNA-X 具有内置的第二个信号源、合路器和内部信号路由开关，能够提供无与伦比的可配置性。
取代机架和堆叠
PNA-X 可以取代机架安装式和堆叠式设备，减少您需要使用的设备数量。
应用软件包括：
· S 参数（连续波和脉冲）
· 噪声系数
· 增益压缩
· 互调和谐波失真
· 转换增益/损耗
· 真正差分激励
· 毫米波
· 非线性波形和 X 参数? 表征
· 天线测试
选件：
N5245A-008
Pulsed-RF Measurements
N5245A-010
Time-domain measurements
N5245A-020
Add IF inputs
N5245A-021
Add pulse modulator to internal first source
N5245A-022
Add pulse modulator to internal second source
N5245A-025
Add four internal pulse generators
N5245A-028
Noise figure measurements using standard receivers
N5245A-029
Fully-Corrected Noise-Figure Measurements to 50 GHz
N5245A-080
Frequency offset measurements
N5245A-082
Scalar calibrated converter measurements
N5245A-083
Vector and scalar calibrated converter measurements
N5245A-084
Embedded LO measurements
N5245A-086
Gain compression application
N5245A-087
Intermodulation distortion measurements
N5245A-088
Source phase control
N5245A-118
Fast CW mode
N5245A-1A7
Calibration + Uncertainties + Guardbanding
N5245A-1CM
Rack mount kit for installation without handles
N5245A-1CP
Rack mount kit for installation with handles
N5245A-200
2 ports, single source
N5245A-219
Add extended power range and bias-tees to 2 port analyzer
N5245A-224
Add internal second source, combiner and mechanical switches to 2-port analyzer
N5245A-301
Application for use with standard CalPods
N5245A-302
Application for use with temperature-characterized CalPods
N5245A-400
4 ports, dual source
N5245A-419
Add extended power range and bias-tees to 4 port analyzer
N5245A-423
Add internal combiner and mechanical switches to 4-port analyzer
N5245A-460
Integrated true-mode stimulus application
N5245A-510
Nonlinear component characterization, full frequency range
N5245A-514
Nonlinear X-Parameters
N5245A-518
Nonlinear pulse envelope domain
N5245A-520
Arbitrary load impedance X-parameters
N5245A-551
N-port calibrated measurements
N5245A-897
Built-in performance test software for inclusive calibration, perpetual license
N5245A-898
Built-in performance test software for standards compliant calibration, perpetual license
N5245A-A6J
ANSI Z540-1-1994 Calibration
N5245A-H08
Pulsed - RF Measurements
N5245A-UK6
Commercial calibration certificate with test data
N1966A
Pulse/IO Adapter
N6171A
