技术参数 |
|||||||
|
型号 |
尺寸 |
连接 |
|||||
|
|
锁定 螺母 外径 |
锁定套 外径 |
有效 高度 |
|
|||
|
|
mm |
in. |
mm |
in. |
mm |
in. |
in. |
|
TMFS 0 |
18 |
0,7 |
22,0 |
0,9 |
45 |
1.8 |
3/8 |
|
TMFS 1 |
22 |
0,9 |
28,0 |
1,1 |
45 |
1.8 |
3/8 |
|
TMFS 2 |
25 |
1.0 |
33,0 |
1,3 |
61 |
2.4 |
1/2 |
|
TMFS 3 |
28 |
1,1 |
36,0 |
1.4 |
61 |
2.4 |
1/2 |
|
TMFS 4 |
32 B |
1,3 |
38,0 |
1.5 |
58 |
2.3 |
1/2 |
|
TMFS 5 |
38 |
1.5 |
46,0 |
1.8 |
58 |
2.3 |
1/2 |
|
TMFS 6 |
M 45 |
1.8 |
53,0 |
2.1 |
58 |
2.3 |
1/2 |
|
TMFS 7 |
52 |
2.0 |
60,0 |
2.4 |
58 |
2.3 |
1/2 |
|
TMFS 8 |
58 |
2.3 |
68,0 |
2.7 |
58 |
2.3 |
1/2 |
|
TMFS 9 |
65 |
2.6 |
73,5 |
2.9 |
63 |
2.5 |
3/4 |
|
TMFS 10 |
70 |
2.8 |
78,5 |
3.1 |
63 |
2.5 |
3/4 |
|
TMFS 11 |
75 |
3.0 |
83,5 |
3.3 |
63 |
2.5 |
3/4 |
|
TMFS 12 |
80 |
3.1 |
88,5 |
3.5 |
63 |
2.5 |
3/4 |
|
TMFS 13 |
85 |
3.3 |
94,0 |
3.7 |
63 |
2.5 |
3/4 |
|
TMFS 14 |
92 |
3.6 |
103,0 |
4.1 |
80 |
3,2 |
1 |
|
TMFS 15 |
98 |
3.9 |
109,0 |
4.3 |
80 |
3,2 |
1 |
|
TMFS 16 |
105 |
4.1 |
116,0 |
4.6 |
80 |
3,2 |
1 |
|
TMFS 17 |
110 |
4.3 |
121,0 |
4.8 |
80 |
3,2 |
1 |
|
TMFS 18 |
120 |
4.7 |
131,0 |
5.2 |
80 |
3,2 |
1 |
|
TMFS 19 |
125 |
4.9 |
137,0 |
5.5 |
80 |
3,2 |
1 |
|
TMFS 20 |
130 |
5.1 |
143,0 |
5.7 |
80 |
3,2 |
1 |
| 密封件选择 | |||
|
型号 |
适用的螺母系列 |
||
|
|
KM、KMK |
KMFE |
DIN 1804 (M) |
|
TMFS 0 |
0 |
|
|
|
TMFS 1 |
1 |
|
|
|
TMFS 2 |
2 |
|
M101 |
|
TMFS 3 |
3 |
|
M12x1.5 |
|
TMFS 4 |
4 |
4 |
M16x1.5 |
|
TMFS 5 |
5 |
5 |
|
|
TMFS 6 |
6 |
6 |
M26x1.5 |
|
TMFS 7 |
7 |
7 |
M32x1,5 |
|
TMFS 8 |
8 |
8 |
M38x1,5 |
|
TMFS 9 |
9 |
9 |
|
|
TMFS 10 |
10 |
10 |
|
|
TMFS 11 |
11 |
11 |
|
|
TMFS 12 |
12 |
12 |
|
|
TMFS 13 |
13 |
13 |
|
|
TMFS 14 |
14 |
14 |
|
|
TMFS 15 |
≥ 15 |
≥ 15 |
|
|
TMFS 16 |
16 |
16 |
|
|
TMFS 17 |
17 |
17 |
|
|
TMFS 18 |
18 |
18 |
|
|
TMFS 19 |
19 |
19 |
|
|
TMFS 20 |
M 20 |
M 20 |
|
