一、 性能特点
Features:
1、采用国内新型的大传动机构，由排链带动主传动轴，免除了其它齿轮传动的误差和噪音。
It adopts the newest type high-power transmission mechanism to arrange the chain and drive the main driving shaft. The errors and noises of other gear wheel transmission can be avoided.
2、电器采用进口控制系统，便可按照客户要求，配置缺料漏补装置和缺粒检测剔除装置。
Imported controlling system is adopted; also it can be equipped with detecting and rejection function device for number of medicines according to the user’s requirement.
3、采用光电控制系统，PVC、PTP、硬铝包装自动送料、废边自动冲切装置，确保超长距离多工位同步稳定性。
It adopts photoelectrical controlling system to make PVC, PTP, Aluminum/Aluminum material to be automatically fed and waste side to be cut automatically to guarantee the Synchronous stability of over- length distance and multi stations.
4、可另配光电检测校正装置，配进口步进电机牵引，图文对版印刷包装，优化包装物档次。
It can be optional equipped with photocell correction device, imported stepper motor traction and image- character register to optimize packing grade.
5、本机适用行业：食品、药品、医疗器械、五金、电子泡罩密封包装。
The machine is suitable for industries of foodstuff, medicine, medical instruments, hardware, electronics and etc for packing.
四：工作流程
Work process
1、 成型（上下加热）
Forming ( up and down heating)
2、 热封（上加热）
Heating Sealing ( up heating)
3、 打码
Embossing
4、 压痕（可微量加热）
Impression
5、 切刀
Cutter
6、 成型输出成品
Finished product output
