风机安装尺寸：
BT35-11-2.8# 330*300 宽X高
BT35-11-3.15# 365*300 宽X高
BT35-11-3.55# 405*330 宽X高
BT35-11-4# 450*340 宽X高
BT35-11-4.5# 500*340 宽X高
BT35-11-5# 550*375 宽X高
BT35-11-5.6# 600*380 宽X高
BT35-11-6.3# 670*470 宽X高
BT35-11-7.1# 770*530 宽X高
BT35-11-8# 870*530 宽X高
BT35-11-9# 970*630 宽X高
BT35-11-10# 1070*640 宽X高
BT35-11-11.2# 1170*640 宽X高
|
机号 |
转速rpm |
叶片角度 |
风量m3/h |
风压Pa |
配用电机 |
A声级Db(A) |
|
|
型号 |
功率kw |
||||||
|
BT35-11-2.8 |
2900 |
35 |
3202 |
232 |
YSF-6300 |
0.25 |
75 |
|
1450 |
35 |
1605 |
60 |
YSF-5024 |
0.12 |
62 |
|
|
BT35-11-3.15 |
2900 |
35 |
4545 |
294 |
YSF-7122 |
0.55 |
79 |
|
1450 |
35 |
2273 |
74 |
YSF-5624 |
0.18 |
65 |
|
|
BT35-11-3.55 |
2900 |
35 |
6542 |
373 |
YSF-8022 |
0.75 |
82 |
|
1450 |
35 |
3265 |
93 |
YSF-6314 |
0.18 |
68 |
|
|
BT35-11-4 |
2900 |
35 |
9336 |
474 |
YF90S-2 |
1.1 |
85 |
|
1450 |
35 |
4687 |
119 |
YSF-7114 |
0.25 |
70 |
|
|
BT35-11-4.5 |
1450 |
35 |
6658 |
150 |
YSF-7124 |
0.37 |
73 |
|
BT35-11-5 |
1450 |
35 |
9133 |
185 |
YSF-8024 |
0.75 |
76 |
|
960 |
35 |
6104 |
81 |
YSF-8026 |
0.37 |
68 |
|
|
BT35-11-5.6 |
1450 |
35 |
12812 |
232 |
YF90S-4 |
1.1 |
79 |
|
960 |
35 |
8471 |
101 |
YSF-8026 |
0.37 |
71 |
|
|
BT35-11-6.3 |
1450 |
35 |
1825 |
294 |
YF100L-4 |
1.5 |
82 |
|
960 |
35 |
12082 |
128 |
YF90S-6 |
0.75 |
74 |
|
|
BT35-11-7.1 |
1450 |
35 |
26120 |
373 |
YF112M-4 |
3 |
84 |
|
960 |
35 |
17296 |
164 |
YF90S-6 |
1.1 |
78 |
|
|
BT35-11-8 |
1450 |
35 |
37070 |
474 |
YF132M-4 |
4 |
86 |
|
960 |
35 |
24739 |
208 |
YF112M-6 |
2.2 |
79 |
|
|
BT35-11-9 |
960 |
35 |
35227 |
263 |
YF132M1-6 |
4 |
82 |
|
BT35-11-10 |
960 |
35 |
48326 |
324 |
YF160M-6 |
5.5 |
83 |
|
BT35-11-11.2 |
960 |
35 |
67892 |
407 |
YF160L-6 |
7.5 |
88 |
