9000-16/25活塞式水锤消除器主要外形尺寸与连接尺寸
|
型号 |
公称通径DN |
法兰直径D |
螺栓孔中心圆直径D1 |
连接凸出部分直径D2 |
法兰厚度b |
总高度H |
螺孔数量直径Z-d |
|
|
mm |
英寸 |
|||||||
|
1.6MPa |
||||||||
|
GY9015 |
15 |
1/2 |
95 |
65 |
45 |
14 |
200 |
4-φ14 |
|
GY9020 |
20 |
3/4 |
105 |
75 |
55 |
16 |
300 |
4-φ14 |
|
GY9025 |
25 |
1 |
115 |
85 |
65 |
16 |
320 |
4-φ14 |
|
GY9032 |
32 |
1 1/2 |
140 |
100 |
78 |
18 |
340 |
4-φ18 |
|
GY9040 |
40 |
1 1/2 |
150 |
110 |
85 |
18 |
350 |
4-φ18 |
|
GY9050 |
50 |
2 |
165 |
125 |
100 |
20 |
455 |
4-φ18 |
|
GY9065 |
65 |
2 1/2 |
185 |
145 |
120 |
20 |
505 |
4-φ18 |
|
GY9080 |
80 |
3 |
200 |
160 |
135 |
20 |
745 |
8-φ18 |
|
GY9100 |
100 |
4 |
220 |
180 |
155 |
22 |
765 |
8-φ18 |
|
GY9125 |
125 |
5 |
250 |
210 |
185 |
22 |
796 |
8-φ18 |
|
GY9150 |
150 |
6 |
285 |
240 |
210 |
24 |
828 |
8-φ23 |
|
GY9200 |
200 |
8 |
340 |
295 |
265 |
24 |
918 |
12-φ23 |
|
GY9250 |
250 |
10 |
405 |
355 |
320 |
26 |
948 |
12-φ25 |
|
GY9300 |
300 |
12 |
460 |
410 |
375 |
28 |
970 |
12-φ25 |
|
|
||||||||
|
GY9015 |
15 |
1/2 |
95 |
65 |
45 |
14 |
220 |
4-φ14 |
|
GY9020 |
20 |
3/4 |
105 |
75 |
55 |
16 |
320 |
4-φ14 |
|
GY9025 |
25 |
1 |
115 |
85 |
65 |
16 |
340 |
4-φ14 |
|
GY9032 |
32 |
1 1/4 |
140 |
100 |
78 |
18 |
350 |
4-φ18 |
|
GY9040 |
40 |
1 1/2 |
150 |
110 |
85 |
18 |
380 |
4-φ18 |
|
GY9050 |
50 |
2 |
165 |
125 |
100 |
20 |
455 |
4-φ18 |
|
GY9065 |
65 |
2 1/2 |
185 |
145 |
120 |
22 |
|
|
