C40P-CDT1-A

C40P-CDT1-A 应用特点：

【厦门光沃自动化设备有限公司】
【联 系 人：陈小姐】
【免费热线：0592-5709825】
【24小时开机：18030229053 】
【工作QQ: 2479261344】

系统配置

    采用5.7”单色触摸屏作为人机界面，设备起停操作在触摸屏上进行，同时用于设定、显示压力及流量数据。压力传感器测量压力，经变送器转换成4～20mA信号接入PLC，电动阀调节压力和流量。

系统配置的模块：

开关量：KINCO-K306-24AR 1个，KINCO-K321-08DT 1个，KINCO-K322-16XR 1个。

模入：KINCO-K331-04IV 1个，采集压力值。

模出：KINCO-K332-02IV 1个，控制电动调节阀。

PLC开关量输入：

    防落油缸回位 I0.1/I0.2 上限位 I0.3，下限位 I0.4

    翻转开限位 I0.6/I0.7 翻转闭限位 I2.0

    翻转锁紧回 I2.1/I2.2 下工作台推出到位 I2.3

    工作台（移动油缸）回限位 I2.4 定位 I2.5/I2.6 顶出限位 I2.7。

PLC开关量输出:

    主油缸快升 Q0.0/Q0.1/Q0.4/Q0.6 加压 Q0.2/Q0.3/Q0.5/Q0.7

    主油缸慢降 Q0.0/Q0.2/Q0.3Q0.7　　 主油缸快降 Q0.1/Q0.3/Q0.5/Q0.7

    翻转开 Q2.0 翻转闭 Q2.1

    翻转锁紧回 Q2.2 防落油缸 Q2.3

    工作台（移动油缸）出 Q2.4　　　　 工作台（移动油缸）回 Q2.5

    定位油缸出 Q2.6 液压泵星角启动Q3.2,Q3.3
