Cut out hole: |
?40mm |
Brand: |
TOPSHALL |
|
Model series: |
MPB40-R4P-FN-S8 |
Safety approval: |
CE and ROHS |
|
Rating: |
5A/250V |
Button and case: |
SUS black etc |
|
Button function: |
Momentary |
Base: |
PA66 |
|
Button shape: |
Flat/high flat |
Contact: |
Silver alloy |
|
Button color: |
Could customize |
Mechanical life: |
500000 cycles |
|
Button led type: |
None |
Dielectric life: |
200000 cycles |
|
Button led color: |
None |
Operate temperature: |
?20-85℃ |
|
Led lamp volt: |
None |
Nut Torque: |
5-14Nm |
|
Lamp life: |
None |
Operating stroke: |
2.0mm±0.3mm |
|
Switch terminals: |
4/8pins with 1NO1NC/2NO2NC |
Contact resistance: |
50m? Max |
|
Protection level: |
IP67 IK09 |
Insulation resistance: |
1000m? Max |
|
Operating pressure: |
500gf±100gf |
Dielectric strength: |
2000VAC 1Am of 1 minute |
