SST25VF032B-80-4I-S2AF有货价格好
深圳市品尚杰电子有限公司      代理销售sst
SST系列产品适用于通讯行业、消费类电子行业，诸如MP3、MP4、GPS、PDA、DVD/VCD、复读机、游戏机、考勤机、机顶盒、数码相机、手机等。该产品的存储器具有速度快、功耗低、稳定性高等优势。该系列产品包括FALES,MCU和串行FALES,其中FALES产品容量从512K到64M,MCU8051从8KB到64KB,串行FALES从512K到32M。
SST的NOR  FLASH（64M以下），SST  FLASH是世界排名前三位的FLASH，它具有扇区小，读写速度快，性能好，价格低廉等特点，应用于电子产品的各大领域，占有广泛的市场
欢迎来电联系。型号特征如下。
FEATURES:
?  Single  Voltage  Read  and  Write  Operations
–  2.7-3.6V
?  Serial  Interface  Architecture
–  SPI  Compatible:  Mode  0  and  Mode  3
?  High  Speed  Clock  Frequency
–  80  MHz  Max
?  Superior  Reliability
–  Endurance:  100,000  Cycles  (typical)
–  Greater  than  100  years  Data  Retention
?  Low  Power  Consumption:
–  Active  Read  Current:  10  mA  (typical)
–  Standby  Current:  5  μA  (typical)
?  Flexible  Erase  Capability
–  Uniform  4  KByte  sectors
–  Uniform  32  KByte  overlay  blocks
–  Uniform  64  KByte  overlay  blocks
?  Fast  Erase  and  Byte-Program:
–  Chip-Erase  Time:  35  ms  (typical)
–  Sector-/Block-Erase  Time:  18  ms  (typical)
–  Byte-Program  Time:  7  μs  (typical)
?  Auto  Address  Increment  (AAI)  Word  Programming
–  Decrease  total  chip  programming  time  over
Byte-Program  operations
?  End-of-Write  Detection
–  Software  polling  the  BUSY  bit  in  Status  Register
–  Busy  Status  readout  on  SO  pin
?  Hold  Pin  (HOLD#)
–  Suspends  a  serial  sequence  to  the  memory
without  deselecting  the  device
?  Write  Protection  (WP#)
–  Enables/Disables  the  Lock-Down  function  of  the
status  register
?  Software  Write  Protection
–  Write  protection  through  Block-Protection  bits  in
status  register
?  Temperature  Range
–  Industrial:  -40°C  to  +85°C
?  Packages  Available
–  8-lead  SOIC  (200  mils)
–  8-contact  WSON  (5  X  6  mm)
?  All  devices  are  RoHS  compli

SST25VF032B-80-4I-S2AF
