SST39VF3201-70-4C-EKE
深圳市品尚杰电子有限公司      代理销售sst
SST系列产品适用于通讯行业、消费类电子行业，诸如MP3、MP4、GPS、PDA、DVD/VCD、复读机、游戏机、考勤机、机顶盒、数码相机、手机等。该产品的存储器具有速度快、功耗低、稳定性高等优势。该系列产品包括FALES,MCU和串行FALES,其中FALES产品容量从512K到64M,MCU8051从8KB到64KB,串行FALES从512K到32M。
SST的NOR  FLASH（64M以下），SST  FLASH是世界排名前三位的FLASH，它具有扇区小，读写速度快，性能好，价格低廉等特点，应用于电子产品的各大领域，占有广泛的市场
欢迎来电联系。型号特征如下。
FEATURES:
?  Organized  as  1M  x16:  SST39VF1601/1602
2M  x16:  SST39VF3201/3202
4M  x16:  SST39VF6401/6402
?  Single  Voltage  Read  and  Write  Operations
–  2.7-3.6V
?  Superior  Reliability
–  Endurance:  100,000  Cycles  (Typical)
–  Greater  than  100  years  Data  Retention
?  Low  Power  Consumption  (typical  values  at  5  MHz)
–  Active  Current:  9  mA  (typical)
–  Standby  Current:  3  μA  (typical)
–  Auto  Low  Power  Mode:  3  μA  (typical)
?  Hardware  Block-Protection/WP#  Input  Pin
–  Top  Block-Protection  (top  32  KWord)
for  SST39VF1602/3202/6402
–  Bottom  Block-Protection  (bottom  32  KWord)
for  SST39VF1601/3201/6401
?  Sector-Erase  Capability
–  Uniform  2  KWord  sectors
?  Block-Erase  Capability
–  Uniform  32  KWord  blocks
?  Chip-Erase  Capability
?  Erase-Suspend/Erase-Resume  Capabilities
?  Hardware  Reset  Pin  (RST#)
?  Security-ID  Feature
–  SST:  128  bits;  User:  128  bits
?  Fast  Read  Access  Time:
–  70  ns
–  90  ns
?  Latched  Address  and  Data
?  Fast  Erase  and  Word-Program:
–  Sector-Erase  Time:  18  ms  (typical)
–  Block-Erase  Time:  18  ms  (typical)
–  Chip-Erase  Time:  40  ms  (typical)
–  Word-Program  Time:  7  μs  (typical)
?  Automatic  Write  Timing
–  Internal  VPP  Generation
?  End-of-Write  Detection
–  Toggle  Bits
–  Data#  Polling
?  CMOS  I/O  Compatibility
?  JEDEC  Standard
–  Flash  EEPROM  Pinouts  and  command  sets
?  Packages  Available
–  48-lead  TSOP  (12mm  x  20mm)
–  48-ball  TFBGA  (6mm  x  8mm)  for  16M  and  32M
–  48-ball  TFBGA  (8mm  x  10mm)  for  64M

SST39VF3201
