30立方工业制氧机

以下是邦诺工业制氧机的详细信息，如果您对工业制氧机的价格、厂家、型号、图片有什么疑问，请联系我们获取工业制氧机的最新信息。咨询热线：0932-5923068 FAX:0932-2234867

工作原理：工业制氧设备 工业氧气设备

工业制氧机根据变压吸附原理，采用沸石分子筛作为吸附剂，由于沸石分子筛有选择吸附的特性，氮被沸石分子筛大量吸附，氧在气相中被富集，在变压吸附的作用下实现氮氧分离。工业制氧机采用两个吸附塔流程，一塔吸附产氧，一塔解吸再生，通过PLC智能程序控制气动角座阀门的启闭，使两塔循环交替，连续交替，连续产出高品质氧气。 Working principle Industrial oxygen machine according to a pressure swing adsorption principle, using zeolite as an adsorbent, the zeolite molecular sieve has selective adsorption characteristics, nitrogen by zeolite molecular sieve absorbs, oxygen in the gas phase is enriched, the PSA is realized under the action of nitrogen and oxygen separation. Industrial oxygen machine adopts the two adsorption towers adsorption oxygen producing process, a tower, a tower desorption regeneration, through the PLC intelligent program control pneumatic angle seat valve opening and closing, so that the two tower alternately, continuously alternating continuous output, high quality oxygen.

产品特点 ●进口气动角座阀，寿命达200万次以上。 ●进口PLC智能程序控制器，操作简便，运动稳定。 ●合理的内部构件，气流分布均匀，减轻气流高速冲击。 ●特有的分子筛保护措施，延长沸石分子筛的使用寿命。 ●自动连锁氧气排空装置，保证产品氧气质量。主要技术参数 Product features ●imported pneumatic angle seat valve, life of more than 2000000. ●The imported PLC intelligent program controller, easy operation, stable movement. ●The reasonable internal structure, uniform air flow distribution, reduce the high-speed airflow impact. ●unique molecular sieve protection measures, extend the service life of zeolite molecular sieve. ●automatic chain oxygen emptying device, to ensure product quality of oxygen. Main technical parameters 技术指标氧气产量：3-150Nm3/h 氧气纯度：90-95% 氧气压力：0.1-0.3 MPa(可提供0.3-3.0MPa）露点：≤-45℃ Technical index Oxygen yield:3-150Nm3/h Oxygen purity:90-95% Oxygen pressure:0.1-0.3MPa (0.3-3.0MPa available ) Dew point:≤ -45 ℃
