供应LC1-D150厂家直销处
公司名称：乐清柳市电器科贸
联系人：曾先生
技术手机：13736770430
销售电话：0577-83283570
报价传真：0577-27872561
网站：www.dqkmgs.com
在线QQ:446023909
额定值
极数        3        3        3        3        4        3        4        3        4        2        3        4        2        3        4        2        3        4
额定电流        A        115        150        170        205        245        300        410        475        620
额定工作电压        V        1000        1000        1000        1000        1000        1000        1000        1000        1000
额定绝缘电压        V        1000        1000        1000        1000        1000        1000        1000        1000        1000
额定冲击耐受电压        KV        8        8        8        8        8        8        8        8        8
工作电流频率范围        Hz        25-400        25-400        25-400        16-200        16-200        16-200        16-200        16-200        16-200
防护等级        主电路        A        200        250        250        315        315        500        630        800        1000
线圈接线端        A        125        160        180        200        250        400        400        500        630
防护处理        106次        8        8        8        10        10        10        10        10        10

工作条件
周围环境温度                贮存                ℃                -60…+80
运行                ℃                -5…+55
允许                ℃                -460…+70
最大运行海拔高度                m                3000
安装方式                                        安装面与垂直面的倾斜度不大于±30℃
搞冲击11ms正弦半波                接触器打开                g                6                6                6                7                7                6                6                6                6
接触器闭合                g                15                15                15                15                15                15                15                15                15
搞振动5-30Hz                接触器打开                g                2                2                2                2                2                2                1.5                2                2
接触器闭合                g                4                4                4                5                5                5                5                4                4
污染等级                                        污染等级Ⅲ
防护等级                主电路                                        IP2LO防止手指直接接触
线圈接线端                                        IP2LO防止手指直接接触
防护处理                                        TH

控制电路特性
额定控制电压                                                                V                24-500                24-1000                42-1000
动作电压                吸合                50H，60Hz                %                0.85-1.1Uc
50Hz/60Hz                %                0.8-1.15Uc                0.85-1.15Uc                0.85-1.1Uc
释放                50H，60Hz                %                0.3-0.5Uc
50Hz/60Hz                %                0.2-0.65Uc
平均功耗                吸合                50Hz                VA                360                -                -                805                805                -                -                -                -
60Hz                VA                360                -                -                970                970                -                -                -                -
50Hz/60Hz                VA                450                450                450                -                -                650                1075                1100                1650
释放                50Hz                VA                22                -                -                55                55                -                -                -                -
60Hz                VA                22                -                -                66                66                -                -                -                -
50Hz/60Hz                VA                6                6                6                -                -                10                15                18                22
最高操作频率，环境温度≤55℃                次/h                2400                1200                1200                2400                2400                1200                1200                1200                1200

产品型号                                        CJX2D        115                CJX2D        150                CJX2D        170                CJX2D        205                CJX2D        245                CJX2D        300                CJX2D        410                CJX2D        475                CJX2D        620
额定电流                A                115                150                170                205                245                300                410                475                620
额定发热电流                A                200                250                250                275                315                400                500                700                1000
额定功率AC3
3相电机
0<40                220/240V                KW                30                40                55                63                75                100                110                147                200
380/400V                KW                55                75                90                110                132
