用途 / Application

一般作動油，符合EN853 1SN / SAE J517 100R1AT。

構造 / Construction

內管層 / Tube

• 耐油性佳之合成橡膠配方。

外管層 / Cover

• 耐油、耐磨、耐候性佳之特殊橡膠配方。

補強層 / Reinforcement

• 1層鋼絲編織。

適用溫度 / Temperature Range

• -40°C to + 100°C
• 使用溫度超過100°C時，會顯著降低夾合膠管之使用壽命。

爆破壓力 / Burst Pressure (B.P)

• 為最高使用壓力的4倍。

長度加壓變化 / Max. change in length

• -4% ~ +2% (在工作壓力下)

規格 / Specification

YOKOHAMA (KINGFLEX)

膠管內徑 Hose I.D.			補強層 Reinforcement		膠管外徑 Hose O.D.	工作壓力 Max. W.P.	爆破壓力 Min. B.P.	最小彎曲半徑 Min. B.R.	約當重量 Approx Wt.
dash	inch	mm	braid	O.D. (mm)	inch (mm)	psi (bar)	psi (bar)	inch (mm)	Lbs./ft (kg/m)
-4	1/4	6.3	1W	0.437 (11.1)	0.527 (13.4)	3,300 (225)	13,200 (900)	4.00 (102)	0.15 (0.23)
-5	5/16	7.9	1W	0.500 ( 12.7)	0.594 (15.1)	3,200 (215)	12,800 (860)	4.50 (114)	0.18 (0.26)
-6	3/8	9.5	1W	0.595 (15.1)	0.685 (17.4)	2,700 (180)	10,800 (720)	5.00 (127)	0.23 (0.34)
-8	1/2	12.7	1W	0.716 (18.2)	0.815 (20.7)	2,400 (160)	9,600 (640)	7.00 (178)	0.28 (0.42)
-10	5/8	15.9	1W	0.843 (21.4)	0.933 (23.7)	1,900 (130)	7,600 (520)	8.00 (203)	0.33 (0.50)
-12	3/4	19.1	1W	1.000 (25.4)	1.094 (27.8)	1,600 (105)	6,400 (420)	9.50 (241)	0.42 (0.63)
-16	1	25.4	1W	1.311 (33.3)	1.406 (35.7)	1,300 (88)	5,200 (352)	12.00 (305)	0.64 (0.94)

YOKOHAMA

膠管內徑 Hose I.D.			補強層 Reinforcement		膠管外徑 Hose O.D.	工作壓力 Max. W.P.	爆破壓力 Min. B.P.	最小彎曲半徑 Min. B.R.	約當重量 Approx Wt.
dash	inch	mm	braid	O.D. mm	mm	Mpa (psi)	Mpa (psi)	mm	g/m
100R1AT-20	1 1/4	31.8	1W	40.5	43.5	4.3 (600)	17.2 (2,500)	420	1,240
100R1AT-24	1 1/2	38.1	1W	46.8	50.2	3.5 (500)	14.0 (2,000)	500	1,530
100R1AT-32	2	50.8	1W	60.3	64.1	2.6 (400)	10.4 (1,500)	630	2,050
