参数Technical Specifications THREE-way full range speaker
频响范围Frequency Response 75Hz~18KHz(±3dB)
低音LOW/Mid Driver 12〞×2
高音HF Driver 75mm×1 B&C
功率Handling Power 700W(RMS)
阻抗lmpedance 8Ω
灵敏度Sensitivity 97dB
连续声压级Maximum Continuous SPL 124dB
声压级Maximum Peak SPL 130dB
扩散角Dispersion 100°Hor×100°Ver
板材Cabinet Construction 11-PLY BIRCH PLYWOOD
表面处理Cabinet Finish polyurethane coating
连接方式input/Output 2×NL4R Speakon
外型尺寸（mm)Cabinet Dimension(mm) W355×H580×L360
功放选用Amp Recommended 600W/8Ω~700W/8Ω
重量Net Weight(kg) 22
