Tab3--Transmitter Section: (Ambient Operating Temperature 0°C to +70°C)
|
Parameter
|
Symbol
|
Min.
|
Typ.
|
Max.
|
Units
|
||
| Data Rate |
B
|
-
|
1250
|
-
|
Mbit/s
|
||
| Center Wavelength |
lo
|
1270
|
1310
|
1360
|
nm
|
||
| Power Supply Current |
Icc
|
-
|
-
|
140
|
mA
|
||
| Data Input Current |
Low
|
IIL
|
-350
|
-
|
-
|
μA
|
|
|
High
|
IIH
|
-
|
-
|
350
|
μA
|
||
| Data Input Voltage |
Low
|
VIL- VCC
|
-1.81
|
-
|
-1.48
|
V
|
|
|
High
|
VIL- VCC
|
-1.17
|
-
|
-0.88
|
V
|
||
| Output Spectral width(RMS) |
Dl
|
-
|
2.5
|
4
|
nm
|
||
| Average Optical Output Power | L(40km) |
Po
|
-5
|
-2
|
+2
|
dBm
|
|
| Extinction Ratio |
ER
|
9
|
-
|
-
|
dB
|
||
| Optical Eye Diagram | Compliant with Bellcore TR-NWT-000253 and ITU-T recommendation G.957 | ||||||
Tab4--Receiver Section: (Ambient Operating Temperature 0°C to +70°C)
|
Parameter
|
Symbol
|
Min.
|
Typ.
|
Max.
|
unit
|
|
| Data Rate |
B
|
-
|
1250
|
-
|
Mb/s
|
|
| Wavelength(DR<10%) |
l
|
1100
|
1310
|
1600
|
nm
|
|
| Power Supply Current |
Icc
|
-
|
-
|
100
|
mA
|
|
| Data Output Voltage |
Low
|
VOL- VCC
|
-1.83
|
-
|
-1.56
|
V
|
|
High
|
VOL- VCC
|
-1.09
|
-
|
-0.88
|
V
|
|
| Maximum Input Power |
Pmax
|
-3
|
-
|
-
|
dBm
|
|
| Receiver Sensitivity |
Sens
|
-
|
-
|
-22
|
dBm
|
|
| Signal Detect Thresholds |
PD
|
-33
|
-
|
-
|
dBm
|
|
|
PA
|
-
|
-
|
-23
|
dBm
|
||
Ordering Information :
BDTR-303S-F113E-SC
| FC | FC Receptacle |
| SC | SC Receptacle |
| T | TTL or LVTTL Signal Detect Output |
| E | PECL or LVPECL Signal Detect Output |
| 1 | 2×5 pinout |
| 3 | 1×9 pinout |
| 1 | 3.3V Power Suply |
| 2 | 5V Power Suply |
| 1 | 0 to +70C |
| 2 | -40 to +85C |
| F | FP Laser Diode |
| D | DFB Laser Diode |
| S | Short Haul Output Power, -15 to -8 dBm (1250M) |
| M | Long Haul Output Power, -10 to -3 dBm(1250M) |
| L | Long Haul Output Power, -5 to +2 dBm (1250M DFB) |
| H | Higher Output Power, -3 to +2dBm(1250M DFB) |
| E | Enlarged distance,0 to +5 dBm(155M) |
| 01 | OC-1 52Mb/s Bit Rate |
| 03 | OC-3 155Mb/s Bit Rate |
| 12 | OC-12 622Mb/s Bit Rate |
| 24 | OC-24 1.25Gb/s Bit Rate |
| 48 | OC-48 2.5Gb/s Bit Rate |
| 0 | 1310nm Tx/1310nm Rx for PTP |
| 2 | 1550nm Tx/1550nm Rx for PTP |
| 3 | 1310nm Tx/1550nm Rx for PTP |
| 5 | 1550 nm Tx/1310nm Rx for PTP |
| BDTR | Fiber Transceiver |
