Features:
l Up to 1.25Gb/s bi-directional data links
l Hot-pluggable SFP footprint
l 850nm , Multimode Fiber
l Duplex LC connector
l Very low jitter
l Up to 550m on Multimode fiber
l Metal enclosure, for lower EMI
l Single 3.3V power supply
l Low power dissipation <700mW typical
Block Diagram of Transceiver:
Application:
Optical Characteristics (TOP = 0 to 70℃, VCC = 3.00 to 3.60 Volts)
|
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Ref. |
|
Transmitter |
||||||
|
Output Opt. Power |
POUT |
-15 |
|
|
dBm |
1 |
|
Optical Wavelength |
λ |
1270 |
1310 |
1360 |
nm |
2 |
|
Optical Modulation Amplitude |
OMA |
174 |
|
|
μW |
2,3 |
|
Optical Rise/Fall Time |
tr/ tf |
|
100 |
160 |
ps |
4 |
|
RIN |
|
|
|
-120 |
dB/Hz |
|
|
Deterministic Jitter Contribution |
TX Δ DJ |
|
20 |
56.5 |
ps |
5 |
|
Total Jitter Contribution |
TX Δ TJ |
|
70 |
119 |
ps |
|
|
Optical Extinction Ratio |
ER |
9 |
|
|
dB |
|
|
Receiver |
||||||
|
Average Rx Sensitivity @ 2.125 |
RSENS1 |
|
|
-21 |
dBm |
6, 7 |
|
Gb/s (2X Fiber Channel) |
|
|
|
|
|
|
|
Average Rx Sensitivity @ 1.25 Gb/s |
RSENS2 |
|
|
-22 |
dBm |
6, 7 |
|
(Gigabit Ethernet) |
|
|
|
|
|
|
|
Average Rx Sensitivity @ 1.06 Gb/s |
RSENS1 |
|
|
-22 |
dBm |
6, 7 |
|
(1X Fiber Channel) |
|
|
|
|
|
|
|
Stressed RX sens. =1.25 Gb/s |
|
|
-18 |
-14.5 |
dBm |
|
|
Average Received Power |
RxMAX |
|
|
0 |
dBm |
|
|
Receiver Elec. 3 dB cutoff freq. |
|
|
|
1500 |
MHz |
|
|
Optical Center Wavelength |
λC |
1265 |
|
1600 |
nm |
|
|
Return Loss |
|
12 |
|
|
dB |
|
|
LOS De-Assert |
LOSD |
|
-23 |
-19 |
dBm |
|
|
LOS Assert |
LOSA |
-30 |
-25 |
|
dBm |
|
|
LOS Hysteresis |
|
0.5 |
|
|
dB |
|
