七、美人蕉酚醛树脂板的技术参数（室内）Technical Performance Index on Phenolic Compact Laminate （TEST，STANDARDFIELDUNIT，FIELD，UNIT，EN 4386，EDF）
1.密度 Density ISO 1183 Mass g/cm3 ≥1.35
2.厚度Thickness EN 438 2-5 5.0≤e≤8.0 8.0≤e≤12.0 mm tol±0.4 tol±0.5
3.平面内变形 Flatness EN 438 2-9 6.0≤e≤10.0 10.0≤e≤- Curve mm ≤5.0 ≤3.0
4.弯曲模数 Bending Module ISO 178 Strength Mpa ≥9000
5.弯曲强度 Bending Stress ISO 178 Strength Mpa ≥80
6.拉伸强度Tensile Strength EN ISO 527-2 Strength Mpa ≥60
7.抗落球冲击 Impact Resistance (Large￠ball) EN438-2-21 Ball drop thickness≥6mm Drop height mm ≥1800
8.耐火性能 Fire Performance EN 13501-1:2002 Classification e≥6mm B-s1.do
9.抗潮性 Moisture Resistance EN438-2-15 Mass increase Appearance mm Grade(table lll) ≤8 ≥4
10.高温下尺寸稳定性 Dimensional Stability at High Temperature EN438-2-17 Accumulated Dimensional Change ％ ≤0.3(L) ≤0.6(T)
