耐高低温地坪 介绍 |
GPU HD200是一种6-12mm厚度,中度止滑,抗冲击,充分耐130℃高温,重载荷水性聚氨酯地坪材料,适用于潮湿及干燥环境。为食品,饮料,乳业,厨房,屠宰,制药,电子,物流等提供理想的耐用地面,因其卓越的(其他环氧等树脂地坪所达不到的)性能受到广大客户的喜爱,尤其是各跨国集团及国内大型集团公司。
GPU HD200是一种中度止滑,抗冲击,耐150℃高温,重载荷水性聚氨酯地坪材料,适用于潮湿及干燥环境。
GPU HD200 is a moderate stop slippery, impact resistant, resistant to high temperature of 150 ℃, heavy load of waterborne polyurethane floor material, suitable for wet and dry environment.
表面效果 Effect of surface:
表面有纹理、哑光聚氨酯砂浆地坪。
Surface texture, matte polyurethane mortar floor.
厚度 Thickness:6.0-12.0毫米
耐高温 High temperature resistant:70-130℃
适用 Fields of Application:
乳制品厂及牛奶加工、制药厂、肉/鱼和家禽加工处理厂、冷冻室、冷冻装置和冷藏设备区域、重型工业化工厂
Dairy farms and milk processing, pharmaceutical factory, meat/fish and poultry processing plant, freezer, refrigeration equipment and refrigeration equipment area, heavy industrial chemical plant
典型性能指标 Typical performance indicators:
(样块完全固化后Specimens cured completely)
项 目 Project |
指 标 Indicators |
项 目 Project |
指 标 Indicators |
密 度 Density |
2090kg/m3 |
抗折强度 Flexural strength |
14 Mpa |
抗拉强度 Tensile strength |
6 Mpa |
与水泥附着力 Adhesion and cement |
水泥面断裂 The cement surface rupture |
抗压强度 The compressive strength |
58 Mpa |
抗压模量 The compressive modulus |
3250 Mpa |
4mm厚的GPU HD200可以充分耐60℃的温度;
6mm厚的GPU HD200可以充分耐70℃高温,且可以进行轻度蒸汽清洗;
9mm 厚的HD200可以充分耐120℃高温且完全可以用蒸汽清洗,因此需要设计非常优秀的基层系统。
4mm thick GPU HD200 can make full 60 ℃ temperature resistance;
6mm thick GPU HD200 can fully 70℃ high temperature resistant, and can be a modest steam cleaning;
9mm thick GPU HD200 can fully 120 ℃ high temperature resistant and can steam cleaning, so need to design very good system at the grass-roots level.
结构示意图:
Structure Profile:
广州固耐特化工有限公司是一家集研发、生产、销售于一体的高新技术企业。主要产品包括:高性能聚氨酯地坪系列、聚氨酯彩砂系列、环氧地坪系列、耐磨硬化地坪系列、重防腐涂料系列、环氧彩砂系列。其成果已广泛应用于食品、医药、电子、生化、电力、五金、市政、商业等各个领域,产销量位于同行业前茅。更多详情查看:http://www.jazdp.com
